- Page 1 Manual Garage Tent 5.4m Series 14-12-2017...
- Page 2 Safety Advice Attention In some countries approval is needed to set up a marquee/tent larger than 75 m2. It is your responsibility to comply with local rules and regulations and to ensure that the marquee/tent is assembled correctly. In case of bad weather conditions, it is your responsibility to ensure the marquee/tent is safely secured and that the marquee/tent does not cause damage to others.
- Page 3 PARTLIST FOR 5.4m series Part no. Description 7,5m 9m 10,5m Female brace 60’’ Corner arch Center arch Male door rail Female door rail T-bar Male brace 63’’ Diagonal 80’’ Rope S-hook Big door rail hook Elastic bungee Floor bracket Nail Carriage bolt 1 ¾’’...
- Page 4 PARTLIST FOR 5.4m series Part no. Description 7,5m 9m 10,5m Wing nut Big plastic cap for legs Small plastic cap for cross pipe Roof Set with door right 23/24 and door left 14-12-2017...
- Page 5 DEAR CUSTOMER Please use gloves when assembling the metal frame portion of this unit. The metal components of this product have been treated with a rust preventive coating that may feel oily to the touch. This coating is not dangerous, but may dirty your hands during assembly. We recommend that you wipe metal parts clean with a mixture of warm water and dish detergent prior to assembly.
- Page 6 3. On each end of (no. 3), install the Leg (no. 1). Repeat step 1 for all frames. 4. At this point stand up the front or back frame and add 7 male connecting pipes (no. 8). Then stand up another frame and add 7 female connecting pipes (no.
