Summary of Contents for SENKO MGT
- Page 1 MGT Docking Station Version II User’s Manual...
-
Page 2: Table Of Contents
MGT Docking Station version II Table Contents …………………………………………………....… Warning …………………………………………....… Overview …………………………………………………....… Specification …………………………………………………....… Button Function …………………………………………………....… LED Color ………………………………………....… Main Operation Procedure ……………………………………....… PC Program Configuration …………………………………....… Log Events Download …………………………………………………....… Limited Warranty... -
Page 3: Warning
MGT Docking Station version II WARNING Any unauthorized attempt to repair or modify the product, or any other cause of damage beyond the range of the intended use, including damage by fire, lightening, or other hazard, voids liability of the manufacturer. -
Page 4: Overview
Gas Ventilation system to remove a remained gas ü Save the log events after calibration and bump test ü Enable users to adjust the setting points of Docking station and MGT via IR ü Link or USB Advantages Gas usage controlled... -
Page 5: Specification
MGT Docking Station version II 2. Specification Size 52.5 x 43.7 x 21.3cm(20.66” x 17.20” x 8.40”) Weight 11.0kg (Without gas cylinder) Operating 41 to +104˚F (5 to +40˚C) Temperature Warranty Full 2 years Battery Type Rechargeable Lithium Ion Battery Life... -
Page 6: Button Function
MGT Docking Station version II 3. Button Function Button Instruction Calibration or Bump To turn on, press either calibration or bump test button for • Test 1 second. (Power Led: Orange -> Green To power off, press the calibration and bump test button •... -
Page 7: Led Color
MGT Docking Station version II 4. LED Color Status LED location Status Color IDLE Power LED Status Green (Ready to use) Unit LED Status Recharging Power LED Status Unit LED Status Blue (Cycling) No USB inserted Power LED Status Orange (Blinking for 5 sec) -
Page 8: Main Operation Procedure
To initiate the calibration or bump test, press the button. And, the power LED will turn orange. The device will decide if the configuration will be loaded on the MGT based on if the configuration check box is marked or not. -
Page 9: Pc Program Configuration
MGT Docking Station version II 6. PC Program Configuration Configuration Calibration interval: 0~365 days Bump interval: 0~365 days Low / High Alarm Setting - H2S : 0 ~ 100.0 - CO : 0 ~ 300 - O2 : 0 ~ 30.0 - LEL : 0 ~ 100.0... -
Page 10: Log Events Download
MGT Docking Station version II 7. Log Events Download Select All : All log events Local Save : Save the log events stored in the docking station. in the PC. Refresh : Open the lists of log events. Docking for PM400 Log Data... -
Page 11: Limited Warranty
MGT Docking Station version II Limited Warranty SENKO warrants this product to be free of defects in workmanship and materials-under normal use and service for two years from the date of purchase from the manufacturer or from the product’s authorized reseller.
