Matrox Maevex Series User Manual page 13

Connector
RS232
USB 2.0
USB 3.0
After connecting your Maevex encoder, we recommend you validate your connection setup before
you continue (see "Validating your Maevex setup", page
Matrox software (see "Installing Matrox PowerStream Plus software", page
Description
Optional – To control an RS232 device (such as a monitor) on one of
your decoders with an RS232 controller connected to an encoder or
with an RS232 controller sending commands over the network.
6150 encoder – Connect one end of your RS232 serial cable to the
connector on your encoder. Connect the other end of the serial cable
to your RS232 device.
If your encoder is set to use the
PowerStream Plus, use a straight through serial cable to connect
your RS232 device to your encoder.
If your encoder is set to use the
PowerStream Plus, use the opposite of the serial cable required by
your RS232 device. (For example, if your RS232 device requires a
null modem cable, use a straight through cable instead.)
Decoder – Connect one end of your RS232 serial cable to the
connector on your decoder. Connect the other end of the serial cable
to your RS232 device. For this connection, use the serial cable (null
modem or straight through) required by your RS232 device.
If your RS232 device has a DB25 connector, use a DE9 (also known as
a DB9) to DB25 converter to connect your device to this connector.
Connect a USB device (such as a flash drive) to this connector.
Connect a USB device (such as an external hard drive) to this connector.
Note: External hard drives must be connected to this connector.
Relayed serial over IP
Direct serial over IP
31). After you validate your setup, install your
37).
Matrox Maevex Series – User Guide 15
feature in
feature in
