5
3
18"
6"
18"
SQ.
MARK 18" DIMENSION
ON EACH LEG BEFORE
INSERTING INTO CONCRETE
NOTE:
THESE ARE TYPICAL
FOOTING DIMENSIONS
FOR AVERAGE SOIL
CONDITIONS. LOCAL
CODE MAY SPECIFY
DIFFERENT REQUIRE-
MENTS.
1
4
2
8
PLEASE NOTE:
1) FOR SAFE OPERATION AND CONTINUED
HIGH PERFORMANCE FROM THIS EQUIPMENT,
INSPECTION AND MAINTENANCE MUST BE
PERFORMED BEFORE EACH USE
2) USE OF THIS EQUIPMENT OTHER THAN
INTENDED, MAY BE HAZARDOUS.
3) ALTERATION OR MODIFICATION OF EQUIP-
MENT MAY BE HAZARDOUS. FOR REPAIR OR
REPLACEMENT, PLEASE CALL YOUR DEALER
IMPORTANT
SEE VIEW
A-A
VIEW A-A
6
7
5
3
Jaypro Sports
976 Hartford Turnpike
Waterford, CT 06385 USA
(800)243-0533
(800)988-3363 Fax
www.jaypro.com
9" TYP
EACH END
76 1/2" TYP
CTR TO CTR
MODEL NO.:
PB-95PI
PRODUCT NAME:
27' PERMANENT PLAYERS BENCH
EFFECTIVE DATE:
DRAWN BY: M T
1/24/2011
