16911
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-800-577-9663
or email:
customerservice@heartlandind.com
Our staff is ready to provide assistance
April through October M-F 8:00 AM to 4:30 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heartland Rockport 8x12 and is the answer not in the manual?

Questions and answers

Richard Berg
April 22, 2025

can you remove 4\4 the shed is sit on after the binging bulit

0
Richard Berg
April 22, 2025

heardland ranch shed

0

Related Manuals for Backyard Heartland Rockport 8x12

Summary of Contents for Backyard Heartland Rockport 8x12

  • Page 1 16911 STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll free number: 1-800-577-9663 or email: customerservice@heartlandind.com Our staff is ready to provide assistance April through October M-F 8:00 AM to 4:30 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 3 16911 05/15/2019 ASSEMBLY MANUAL A Backyard Products Company ROCKPORT 8' x 12' (244 x 366 cm) ACTUAL FLOOR SIZE IS 96" x 140-5/8" (243,8 x 357,2 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE IMPORTAN T ! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY.
  • Page 4 TOOLS Required Optional Phillips ❑ Tool Belt/ ❑ Utility Knife ❑ Screwdriver Nail Pouch Shingle Blades ❑ Drill / Driver ❑ 1/8" Drill Bit ❑ Tin Snips ❑ 1/4" Drill Bit ❑ Caulk Gun ❑ (for drip edge) 5/16" Drill Bit ❑...
  • Page 5 ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed kit includes a complete wood floor system. • This shed kit does not include ANY leveling materials. • See the FLOOR LEVELING section on page 7 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site.
  • Page 6 PARTS IDENTIFICATION AND SIZES Part identification WOOD SIZE CONVERSION CHART letters are stamped on some parts. All treated lumber Nominal Board Size Actual Size is stamped: 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 7 PARTS LIST continued... WITH WOOD GRAIN ON FACE 7-1/4 x 18-1/4" (18,4 x 46,4 cm) 19/32 x 6-15/16 x 5-1/2" (1,5 x 17,6 x 13,4 cm) 19/32 x 6-15/16 x 5-1/2" (1,5 x 17,6 x 13,4 cm) 2 x 3 x 68-7/16" (5,1 x 7,6 x 173,8 cm) 2 x 3 x 7-7/8"...
  • Page 8 WALL PANEL & DOORS PARTS LIST 3/8 x 48 x 72" 3/8 x 44-5/8 x 72" LEFT DOOR RIGHT DOOR 3/8 x 19-5/8 x 72" (1 x 121,9 x 182,9 cm) (1 x 113,3 x 182,9 cm) (1 x 49,8 x 182,9 cm) NAIL BOXES 3"...
  • Page 9 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS • 3" Screws angled into 4x4. • (2) at each point frame •...
  • Page 10 CONCRETE FOUNDATION Your kit contains all materials to construct a wooden floor. If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4"...
  • Page 11 FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 92-5/8" (5,1 x 10,2 x 235,3 cm) 2 x 4 x 93" (5,1 x 10,2 x 236,2 cm) BEGIN Orient parts as shown on flat surface.
  • Page 12 LEVEL AND SQUARE FLOOR FRAME Before attaching floor decking, it is important to level and square the floor frame. A level and square floor frame is required to correctly construct your shed. BEGIN See page 7 for the preferred floor leveling method. Use a level and check that the frame is level before installing floor panels.
  • Page 13 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 5/8 x 48 x 96" (1,6 x 121,9 x 243,8 cm) Ensure your floor frame is square by installing (1) panel and squaring frame. BEGIN Install a 48" x 96" panel with the rough side up (painted-grid lines side) and with the 48" edge and corner flush to the floor frame (Fig A).
  • Page 14 FLOOR PANELS PARTS REQUIRED: x110 2" (5,1 cm) 3/4" GAUGE BLOCK 5/8 x 48 x 96" 5/8 x 44-5/8 x 96" (1,6 x 121,9 x 243,8 cm) (1,6 x 113,3 x 243,8 cm) Continue installing panels with rough side up (painted grid lines). Install 44-5/8"...
  • Page 15 IMPORTANT! Check that the floor frame is level after installing floor panels. Re-level if needed. • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process HINT: to avoid over-handling of the walls. BACK WALL RIGHT WALL LEFT WALL...
  • Page 16 LEFT WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 68-5/8" (5,1 x 10,2 x 174,3 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) HINT: LEFT RIGHT...
  • Page 17 LEFT SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48 x 72" (121,9 x 213,4 cm) BLOCK INSTALL ALL WALL PANELS WITH THE PRIMED SIDE FACING OUTWARD Ensure your wall frame is square by installing one panel and squaring frame. BEGIN Place 48"...
  • Page 18 LEFT SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48 x 72" 44-5/8 x 72" (121,9 x 213,4 cm) (121,9 x 213,4 cm) For squareness maintain flush and 3/4" measurement along panel edges. Place center 48" x 72" panel on frame as shown with primed side facing up.
  • Page 19 RIGHT WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 68-5/8" (5,1 x 10,2 x 174,3 cm) 2 x 4 x 72" (5,1 x 10,2 x 182,9 cm) BEGIN Orient parts on edge on floor.
  • Page 20 RIGHT SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48 x 72" (121,9 x 213,4 cm) INSTALL ALL WALL PANELS WITH THE PRIMED SIDE FACING UP Ensure your wall frame is square by installing (1) panel and squaring frame. Place 48 x 72"...
  • Page 21 RIGHT SIDE WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48 x 72" 44-5/8 x 72" (121,9 x 213,4 cm) (121,9 x 213,4 cm) For squareness maintain flush and 3/4" measurement along panel edges. Place center 48" x 72" panel on frame as shown with primed side facing up.
  • Page 22 BACK WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 89" (5 x 10,2 x 226,1 cm) 2 x 4 x 68" (5 x 10,2 x 172,7 cm) ¸ BEGIN Orient parts on edge on floor. Measure and mark. Secure using (2) 3"...
  • Page 23 BACK WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 3/8 x 48 x 72" (1 x 121,9 x 182,9 cm) INSTALL ALL WALL PANELS WITH THE PRIMED SIDE FACING UP Place 48" x 72" panel onto wall frame as shown. Use the gauge block to mark the 3/4"...
  • Page 24 BACK WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/8 x 48 x 72" (1 x 121,9 x 182,9 cm) Place 2nd 48" x 72" panel onto wall frame, flush to installed panel. Secure panel using 2" nails 6" apart on edges and 12" apart inside panel. Flush 3/4"...
  • Page 25 BACK WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) Center PT on back wall top plate and flush to inside of back of wall panel (Fig. A). Secure PT to top plate using (8) 3" screws. Fig.
  • Page 26 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 16-1/2" (5,1 x 10,2 x 41,9 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 89" (5 x 10,2 x 226,1 cm) INSTALL ALL WALL PANELS WITH THE PRIMED SIDE FACING UP BEGIN Orient parts on edge on floor.
  • Page 27 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 6,3 x 175,3 cm) TEMPORARY SUPPORT 2" (5,1 cm) 3/8 x 19-5/8 x 72" (1 x 49,8 x 182,9 cm) Place 19-5/8" x 72" panel onto wall frame flush to SZ with primed side up as shown.
  • Page 28 FRONT WALL PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 84" (5,1 x 7,6 x 213,4 cm) Center FW on the 2-1/2" side of SZ flush to edge (Fig. A, B). Secure using (5) 3" screws on angle and spaced evenly. Flush Fig.
  • Page 29 RIGHT SIDE WALL INSTALLATION PARTS REQUIRED 3" (7,6 cm) TEMPORARY 2 x 4 x 69-7/8" (5,1 x 10,2 x 177,5 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center right sidewall assembly on the 140-5/8" floor dimension. ENSURE 20-5/8" MEASUREMENT IS TOWARD BACK OF SHED 20-5/8"...
  • Page 30 LEFT SIDE WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) TEMPORARY 2 x 4 x 69-7/8" (5,1 x 10,2 x 177,5 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center left sidewall assembly on the 140-5/8" floor dimension. Install 1" wall panel overhang toward the bottom. Install WW as a temporary brace.
  • Page 31 BACK WALL INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) BEGIN Set back wall on side wall top plates between left and right walls. Secure wall using 3" screws into left and right wall top and bottom plates (Fig. A). Fig.
  • Page 32 BACK WALL INSTALLATION PARTS REQUIRED: 1-1/2" (3,8 cm) 3" (7,6 cm) Nail lower edge of back wall panels to floor using 2" nails 6" apart. Angle nail to hit floor frame (Fig. B). Secure bottom plates to floor using 3" nails (Fig. B). Secure top plates to side walls using (2) 3"...
  • Page 33 FRONT WALL INSTALLATION PARTS REQUIRED: 2" (5,1 cm) 3" (7,6 cm) 1-1/2" (3,8 cm) 3" (7,6 cm) BEGIN Place front wall on floor between side walls. Secure top plate to side walls using (2) 3" nails (Fig. A, B, E ). Nail front wall panels to side wall using 1-1/2"...
  • Page 34 RAFTERS PARTS REQUIRED: x132 3" (7,6 cm) 2" (5,1 cm) OSB OR WOOD GRAIN 7-1/4 x 18-1/4" (18,4 x 46,4 cm) 2 x 3 x 7-7/8" (5,1 x 7,6 x20 cm) 2 x 4 x 68-7/16" (5,1 x 10,2 x 173,8 cm) TEMPORARY SUPPORT ¸...
  • Page 35 RAFTERS PARTS REQUIRED: 3" (7,6 cm) (1) GUSSET Preassembled Preassembled ¸ BEGIN Install the (1) GUSSET rafter aligned with front stud, flush to inside of front wall panelsc and tight to side wall (Fig. A, B). Face gusset inward. Rest notch on top plate. Secure rafter to top plate using (2) 3"...
  • Page 36 FRONT WALL GABLE PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 6-1/2" (5,1 x 10,2 x 18,4 cm) 2 x 4 x 17-1/2" (5,1 x 10,2 x 44,5 cm) BEGIN Place left front gable panel on YG and UY as shown. 1-3/4"...
  • Page 37 BACK WALL GABLE PARTS REQUIRED: 1-1/2" (3,8 cm) 2 x 4 x 37-3/4" (5,1 x 10,2 x 95,9 cm) BEGIN Place left back gable panel on YFB as shown. 3-1/2" (8,9 cm) Secure using 1-1/2" nails 6" apart. 1-3/4" (4,5 cm) Place right back gable panel on YFB flush to left panel.
  • Page 38 FRONT WALL GABLE PARTS REQUIRED: 1-1/2" (3,8 cm) Preassembled BEGIN Caulk on top of front wall panels first as shown. Place front gable assembly centered on front wall and flush to rafter peak (Fig. A). Secure front gable panels into top plate using 1-1/2" nails, 6" apart. Support rafter and gable while securing gable panels to rafter using 1-1/2"...
  • Page 39 BACK WALL (Gable Z-Strip) PARTS REQUIRED: 2" (5,1 cm) 96" (243,8 cm) Z-STRIP BEGIN Center Z-Strip on back wall panels (Fig. A). Secure Z-Strip to PT using (8) 2" finish nails 16" apart. Fig. A 2" (5,1 cm) Finish Nails 2"...
  • Page 40 BACK WALL GABLE PARTS REQUIRED: 1-1/2" (3,8 cm) Preassembled BEGIN Center back wall gable assembly on z-strip. Gable panels should be flush to wall panel as shown (Fig. A). Secure gable assembly to PT using 2" nails 6" apart. Fig. A 2"...
  • Page 41 BACK GABLE TRIM PARTS REQUIRED: 1-1/4" (3,2 cm) 2 x 4 x 69-7/8" (5,1 x 10,2 x 177,5 cm) BEGIN Position (1) WW flush to back gable panel edge and center with panel seam (Fig. A) . Secure trim using (10) 1-1/4" screws from inside, approximately 7" apart. Position second WW flush to panel edge and flush to WW already attached (Fig.
  • Page 42 FRONT WALL OVERHANG FRAMING PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 68-7/16" (5,1 x 7,6 x 173,8 cm) 2 x 3 x 7-7/8" (5,1 x 7,6 x 20 cm) BUILD FOUR OVERHANG FRAMES BEGIN Orient parts on flat as shown. Flush 4" angled corner of WE to DY as shown. Secure WE to DY using (1) 3"...
  • Page 43 FRONT WALL OVERHANG PARTS REQUIRED: 3" (7,6 cm) 3/8" x 2" x 5" 2" (5,1 cm) (1 x 5,1 x 30,2 cm) Pre-assembled BEGIN Position 2" x 5" spacer flush to front of rafter and wall panel. Secure using (2) 2" nails (Fig. A). Position overhang framing flush to rafter (Fig.
  • Page 44 FRONT WALL OVERHANG PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 7-7/8 x 57-7/8" (1 x 20 x 147 cm) INSTALL ALL OVERHANG PANELS WITH THE PRIMED SIDE FACING OUTWARD Position both 57-7/8" overhang boards flush to front wall (Fig A). Secure using (12) 1-1/4"...
  • Page 45 FRONT WALL OVERHANG PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 7-7/8 x 7-7/8" (1 x 20 x 20 cm) Install (2) 7-7/8" x 7-7/8" overhang boards flush to front wall and soffit block (Fig. A, Fig. B). Secure using (2) 1-1/4" screws. Fig.
  • Page 46 FRONT WALL OVERHANG PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 5-13/16 x 7-7/8" (1 x 14,8 x 20 cm) Install (2) 5-13/16" x 7-7/8" overhang boards flush to front wall and to previously installed overhang boards (Fig. A, Fig. B). Secure using (2) 1-1/4"...
  • Page 47 FRONT WALL OVERHANG PARTS REQUIRED: 3" (7,6 cm) 1-1/4" (3,2 cm) Preassembled Position overhang framing flush to front of overhang boards. (Fig. A). Secure bottom of pre-assembled overhang first using (3) 1-1/4" screws. Continue securing overhang frame, working upward toward peak. Repeat STEP 10 on opposite side.
  • Page 48 FRONT WALL OVERHANG PARTS REQUIRED: 2" (5,1 cm) 19/32 x 4 x 69-7/8" (1,5 x 10,2 x 177,5 cm) 19/32 x 4 x 69-7/8" (1,5 x 10,2 x 177,5 cm) Position WML with primed side out, flush to peak and to overhang framing (Fig. A). Secure using 2"...
  • Page 49 SOFFIT NAILER PARTS REQUIRED: USE AS GAUGE BLOCK 2 x 3 x 5-1/8" (5,1 x 7,6 x 13 cm) 2" (5,1 cm) 1 x 2 x 43-1/2" (2,5 x 5,1 x 110,5 cm) 1 x 2 x 96" (2,5 x 5,1 x 243,8 cm) BEGIN Place a square flush to bottom side of rafter and side wall (Fig.
  • Page 50 SOFFIT BLOCK PARTS REQUIRED: 2-1/2" (6,4cm) 2 x 3 x 5-1/8" (5,1 x 7,6 x 13 cm) BEGIN Position WD flush against side wall and bottom of WS. Secure using (3) 2-1/2" screws as shown (Fig. A). Repeat STEP 1 for opposite side (Fig. B). Fig.
  • Page 51 SOFFIT PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 5-3/16 x 69-3/8" (1 x 13,2 x 176,2 cm) 3/8 x 5-3/16 x 72" (1 x 13,2 x 182,9 cm) BEGIN Place 72" soffit board primed side down on bottom side of rafter and nailer (Fig.
  • Page 52 BACK WALL SOFFIT CAP PARTS REQUIRED: 2" (5,1 cm) 19/32 x 6-15/16 x 5-1/2" (1,5 x 17,6 x 13,4 cm) 19/32 x 6-15/16 x 5-1/2" (1,5 x 17,6 x 13,4 cm) BEGIN Position LEFT corner soffit cap primed side out on back wall using 6-15/16" measurement down and flush to bottom of soffit board as shown.
  • Page 53 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 7/16 x 8-7/8 x 70" (1,1 x 22,5 x 177,8 cm) 7/16 x 47-7/8 x 48" (1,1 x 121,6 x 121,9 cm) 3/4" GAUGE 7/16 x 22 x 46-1/2" BLOCK (1,1 x 55,9 x 118,1 cm) 7/16 x 22 x 96"...
  • Page 54 ROOF PANELS PARTS REQUIRED: x208 2" (5,1 cm) Fig. E Keep spacing between the center of the NOTE: Measurement from outside of trim. rafters at the lower edge of the panel and secure with (1) 2" nail into each 22-1/2" 24"...
  • Page 55 COLLAR TIES PARTS REQUIRED: 3" (7,6 cm) 1 x 4 x 46-1/2" (2,5 x 10,2 x 118,1 cm) BEGIN Position and level (2) TKA collar ties on 2nd and 4th rafter from back wall. HINT: For best appearance install collar tie on rafter facing away from door opening.
  • Page 56 FRONT WALL DECORATIVE TRIM PARTS REQUIRED: 2" (5,1 cm) 5-11/16 x 7-13/16" (14,4 x 19,8 cm) 7-1/4 x 18-1/4" (18,4 x 46,4 cm) WITH WOOD GRAIN ON FACE 5-11/16 x 7-13/16" (14,4 x 19,8 cm) BEGIN Position left and right corner soffit cap Primed Side Out flush to bottom of overhang as shown. Secure using (3) 2"...
  • Page 57 EAVE FASCIA BOARDS PARTS REQUIRED: 2" (5,1 cm) 3/8 x 2-3/4 x 80-1/4" (1 x 7 x 203,8 cm) 3/8 x 2-3/4 x 69" (1 x 7 x 175,3 cm) ¸ BEGIN Install fascia boards flush to rafters and flush to roof panels (Fig. A). Secure using (2) 2"...
  • Page 58 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) 1-1/4" (3,2 cm) 1 x 3 x 5" (2,5 x 7,6 x 12,7 cm) Left Door Assembled Right Door Assembled BEGIN Orient parts as shown on flat surface. 3/8"...
  • Page 59 DOORS PARTS REQUIRED: 3" (7,6 cm) 1-1/2 x 2-1/2 x 69" (3,8 x 6,3 x 175,3 cm) BEGIN Attach temporary support OO as a ledger board flush under wall panels for doors to rest on, using (3) 3" screws (Fig. A). Fig.
  • Page 60 DOOR PARTS REQUIRED: 2" (5,1 cm) 3/4" (1,9 cm) 19/32 x 2-1/2 x 63" (1,5 x 6,4 x 160 cm) 3/4" (1,9 cm) x9 Bagged separately / special coating 19/32 x 3 x 23" (1,5 x 7,6 x 58,4 cm) 56"...
  • Page 61 WINDOWS PARTS REQUIRED: 1-1/4" (3,2 cm) 10-1/2 x 32-1/2" (26,7 x 82,6 cm) ¸ BEGIN Apply high quality exterior-grade caulk behind frame near edge before installing to seal window. From outside of shed, position window in opening and level. Use (2) screws at top of windows. Do not fully tighten screws.
  • Page 62 WINDOWS TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32 x 2-1/2 x 9" (1,5 x 6,4 x 22,9 cm) 19/32 x 2-1/2 x 36-3/4" (1,5 x 6,4 x 93,3 cm) Center WA 3/4" onto window frame. Secure using (2) 2" finish nails as shown. Do not nail into window flange.
  • Page 63 WINDOWS PARTS REQUIRED: 3/4" (1,9 cm) From inside, snip or bend-over protruding finish nails. Install 3/4" screws as shown. Do not screw into window flange. INSIDE OF SHED 3/4" (1,9 cm) Screws Snip off 2" nails protruding through panel. FINISH Your window is now installed.
  • Page 64 DOOR WEATHERSTRIP PARTS REQUIRED: 2" (5,1 cm) 1-1/4 x 2-1/2 x 69" (3,2 x 7,6 x 175,3 cm) BEGIN Center OO’s vertically on the left and right doors as shown (Fig. A, Fig. B). Secure using (7) 2" screws through outside trim into OO (Fig. B). Center OO in door opening.
  • Page 65 DOOR PARTS REQUIRED: 1" (2,5 cm) 5/16" (0,8 cm) Drill Bit BEGIN Place upper bolt onto OO in open position with bolt end 3/8" down from frame. Bolt is open when loop is contacting base (Fig A) . Mark and pre-drill holes for screws. Install bolt using screws supplied and drill 5/16"...
  • Page 66 DOOR HARDWARE / DECORATIVE HINGES PARTS REQUIRED: 1-1/2" (3,8 cm) 1/2" (1,3 cm) Drill Bit 3/4" (1,9 cm) 1/4" (0,6 cm) Drill Bit BEGIN Measure and mark location of hole on outside of right door as shown (Fig. A) . Pre-drill hole using a 1/4"...
  • Page 67 TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8 x 1-3/4 x 67-3/4" (1 x 4,4 x 172,1 cm) ¸ BEGIN Attach corner trim as shown using 2" finish nails. 67-3/4" (172,1 cm) Flush under gable panel 67-3/4" (172,1 cm) Seam is flush. Caulk seam before painting trim.
  • Page 68 HOOK & EYE PARTS REQUIRED: Hook ¸ BEGIN Install hook into endcap and into 2x3 behind as shown (Fig.A). Swing door open to locate eye. Repeat installation for 2nd hook and eye (Fig.A). Fig. A Hook 2" 1" Install hook on inside face 2" up from bottom and 1"...
  • Page 69 VENTS PARTS REQUIRED: 1/2" (1,3 cm) 8" x 16" (20,3 x 35,6 cm) ¸ BEGIN Locate and mark for one vent in side wall and one vent in the back wall gable. Caulk behind vent flanges. Secure using 1/2" screws. Caulk Center 6"...
  • Page 70 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 71 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2 " 1" Sealing Str 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 72 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 73 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 74 SHINGLES - RIDGE CAP • You will finish off the top of the roof using a ridge cap made from shingles. BEGIN Cut shingles into (3) pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 75 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. 4" (10 cm) Trim cap off flush to shingles When you have 4" minimum of shingle color cut (1) piece to cap your roof. Cut at top of rain slot.
  • Page 76 Storage Buildings To validate your warranty, it is necessary to properly maintain your Backyard Storage Solutions, LLC unit; shingle the roof and paint or solid-colored stain the siding using quality, 100% acrylic latex exterior product with a minimum of two (2) coats within thirty (30) days of assembly;...
