ZyXEL Communications HOMEBOUND TRIPLE PLAY DELIVERY ES-315 Specifications

4 ports Auto Crossover MDI/MDI-X
10/100 Mbps and 1 Port FX
Compliant with IEEE 802.3u/x
(ES-315-F)
5 ports Auto Crossover MDI/MDI-X
10/100 Mbps Compliant with
IEEE 802.3u/x (ES-315)
1K Layer 2 MAC Addresses Table
Support 512K bits SRAM for
Packet Buffer
802.1D Transparent Bridging
IEEE 802.1Q Tag-based VLAN
IGMP Snooping
Fan-less Design
IGMP Filtering
MVR
5-port FE Intelligent
Layer 2 Managed Switch
ES-315
ES-315-F
Homebound Triple Play Delivery
Benefits
Easy 5-port L2 Managed Switch Deployments
ZyXEL ES-315/315-F is a L2 premise-managed Ethernet switch with up to 4 10/100 Mbps auto-
crossover MDI/MDI-X ports and 1 FX port or 5 10/100 Mbps auto-crossover MDI/MDI-X ports. With
superb performance in network resiliency, QoS, IP multicasting and security, the ES-315/315-F is an
ideal triple-play service solution for active Ethernet ETTx deployments aiming at service providers as
well as cable, utility and municipality operators.
Secured Service-level IP TV & VoIP Operations
To IP TV and VoIP services, the quality is the key to success. As such ES-315/ES-315-F comes with
proven QoS and VLAN functionalities like multi-layer (L2/L3/L4) ACL and 4 priority queues with
SP/WRR to ensure smooth operations. For the hottest IP TV services, the ES-315/315-F also supports
MVR to work with the IGMP snooping feature that empowers commercial-class IP TV deliveries.
