GB
SE Pro-RC
Quick Start Guide commeo / SE Pro-RC
Contents
1. Connection drive ................................................................................................................. 2
2. Set drive to initial operation and select (SELECT-mode) ..................................................... 2
3. Funktion in the SELECT-mode ............................................................................................. 3
3.1. Automatic setup-mode (bottom position, top stop/release) .......................................... 4
3.2. Manual setup-mode (bottom position, top position) ...................................................... 4
3.3. Manual setup-mode (bottom position, top stop/release) ............................................... 4
3.4. Programming/deleting transmitters ................................................................................ 5
3.5. Delete all transmitters in the drive .................................................................................. 5
3.6. Reset the drive in to the factory setting .......................................................................... 5
4. Reset drive with setting cable to factory settings ............................................................... 6
5. Delete all drives in the tansmitter ...................................................................................... 6
6. Set intermediate position ................................................................................................... 7
7. Set ventilation/tilt ............................................................................................................... 7
8. SELVE Service Hotline .......................................................................................................... 8
Release date 09/2019
Reserve technical changes

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Commeo SE Pro-RC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Selve Commeo SE Pro-RC

Summary of Contents for Selve Commeo SE Pro-RC

  • Page 1: Table Of Contents

    4. Reset drive with setting cable to factory settings ............... 6 5. Delete all drives in the tansmitter ..................6 6. Set intermediate position ....................7 7. Set ventilation/tilt ....................... 7 8. SELVE Service Hotline ......................8 Release date 09/2019 Reserve technical changes...

  • Page 2: Connection Drive

    1. Connection drive Without external switch / button With external switch / button 1: PE, green-yellow 2: L1, brown 3: DOWN, black 4: UP, gray 5: N, blue 2. Set drive to initial operation and select (SELECT-mode) Start SELECT-mode Select the drive Finish With power failure Status-LED...

  • Page 3: Funktion In The Select-Mode

    3. Funktion in the SELECT-mode Start SELECT- Keypress Adjustment mode Automatic setup-mode, deletion and automatic setting of the end positions  in operation bottom position, top stop/release (see 3.1.) Manual setup-mode, deletion and manual setting of the end positions  in operation bottom position, top position (see 3.2.) ...

  • Page 4: Automatic Setup-Mode (Bottom Position, Top Stop/Release)

    3.1. Automatic setup-mode (bottom position, top stop/release) Press and hold the buttons. First drive top stop. Start Finish Drive automatically finds stop positions. 3.2. Manual setup-mode (bottom position, top position) Start Finish Lower end position Upper end position 3.3. Manual setup-mode (bottom position, top stop/release) Start Beenden Lower end position...

  • Page 5: Programming/Deleting Transmitters

    3.4. Programming/deleting transmitters Status-LED lights up Transmitter programmed. Status-LED lights up Start Finish  Transmitter deleted. Note: Repeated presses will transmitter programming and deleting alternately. 3.5. Delete all transmitters in the drive All transmitters in the drive are deleted. Start Finish Note: Can lead to errors in more learned transmitters.

  • Page 6: Reset Drive With Setting Cable To Factory Settings

    4. Reset drive with setting cable to factory settings Connect setting cable The drive makes a short drive and is in the factory delivery condition. The end positions and all transmitters are deleted. > 12 s Note: Can lead to errors in more learned transmitters 5.

  • Page 7: Set Intermediate Position

    6. Set intermediate position >3 s Release STOP save Press and hold the the position buttons 7. Set ventilation/tilt >3 s Press and hold the Release STOP save buttons the position...

  • Page 8: Selve Service Hotline

    8. SELVE Service Hotline • Hotline: Phone +49 2351 925-299 • Download the manuals at www.selve.de or QRscan SELVE GmbH & Co. KG Werdohler Landstraße 286 D-58513 Lüdenscheid Tel.: +49 2351 925-299 Fax: +49 2351 925-111 Internet: www.selve.de E-Mail: info@selve.de...
