Page 1: Quick Start Guide
P-660H-D Series ADSL2+ 4-port Gateway Quick Start Guide Version 3.40 Edition 2 3/2006... -
Page 2: Hardware Connections
Overview The P-660H-D is an ADSL router with a four-port built-in switch. See your User’s Guide for background information on all features. How to use the included CD This CD provides multi-media animations that help you set up your P-660H-D. 1 On the included CD, click Multimedia Auto Provisioner >... -
Page 3: Status Page
3 POWER: Use the power adaptor provided with your P-660H-D to connect an appropriate power source to the POWER socket. Make sure the power source is on. 4 Push in the POWER button. Look at the lights on the front panel. •... -
Page 4: Internet Setup
3 See the User’s Guide for field descriptions of the Status screen. 3 Internet Setup 1 Open your web browser, and go to http://www.zyxel.com. Your P-660H-D tries to detect your Internet connection. Wait for the P-660H-D to finish detection. If any other screens appear, follow the directions in the screen. -
Page 5: Troubleshooting
4 Follow the directions in the screens. 5 Click Go to Wizard setup. Then, click Apply. 6 Click INTERNET SETUP. Wait while your P-660H-D tries to detect your DSL connection. 7 Follow the directions in the wizard. Do not change default settings if your ISP did not provide information. Troubleshooting 1 If you cannot access the web configurator using Internet Explorer in Windows XP or Windows Server 2003, make sure you allow pop-up windows, JavaScripts and Java permissions or set the Internet security level... - Page 6 A) Check the lights on the front panel. If they are different than what is described in section 1, make sure the connections are correct. (See section 1.) If the lights are still different, turn off the device, wait a few seconds, and turn it on again.
