Global 248448 Instructions

Exhaust Fan_Single Speed _248448_2944495-294497
Customer Service
US: 888-628-3466
Canada: 888-645-2986
Mexico: 01.800.681.6940
WARNING
•TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
INJURY TO PERSONS, OBSERVE THE FOLLOWING:
• This product contains chemicals which are known to the
state of California to cause birth defects or other
reproductive harm.
• This exhaust fan is not for use in explosive or combustible
atmospheres.
• Read and follow all instructions before operating fan.
• Do not use fan if any part is damaged or missing.
• Do not alter the fan's assembly.
• All electrical connections should be made by a qualified
electrician. Installation work and electrical wiring must be
done by qualified person(s) following all local electrical and
safety codes in the United States and Canada, as well as
the National electrical Code (NEC) and the Occupational
Safety and Health Act (OSHA) in the United States, and the
Canadian Electric Code (CEC) in Canada.
• Use OSHA approved lock-out tag-out devices on power
supply to prevent shock and/or electrocution.
• When cutting or drilling into wall or ceiling, do not damage
electrical wiring and other hidden utilities.
• To reduce the risk of fire or electrical shock, do not expose to
water or rain.
• To reduce the risk of fire or electrical shock, do not use this
fan with any solid state speed control device.
• To reduce the risk of fire or electrical shock, do not use an
extension cord, unit is intended to be permanently hard
wired to properly rated electrical service outlet (120V 60Hz).
8/15/14
globalindustrial.com
Single Speed Exhaust Fan
READ & SAVE THESE INSTRUCTIONS
8:18 AM Page 2
• To reduce the risk of injury to persons, install fan at least 7
feet (2.1m) above the floor (8 feet in Canada).
• The fan frame and motor must be electrically grounded to a
suitable electrical ground, such as a grounded water pipe or
ground wire system.
• This has a single speed motor which is equipped with a
thermo – protector and will automatically de-energize the fan
if it overheats for any reason.
RULES FOR SAFE OPERATION:
1. Never insert fingers or any other objects through the grill
guard when fan is in operation.
2. Install in interior wall. Not for use in kitchens.
3. Disconnect the fan from its power source when removing
guards for cleaning.
4. Do not use the fan in windows. Rain and moisture may
create electrical hazard.
5. Do not place the fan near an open flame, cooking or heating
appliance, or hot surface.
6. This fan is for indoor dry applications.
7. This fan should not be operated outside.
8. For proper exhaust operation, a window, door, or louver
should be opened on the opposite side of the area to be
ventilated.
9. Periodically clean the propeller, guard, motor, and louver of
any accumulated dirt.
1
Assembly
Instructions
Models
Fan With Shutter
248448 - 10"
294495 - 12"
294496 - 18"
294497 - 24"
Fan
246506 - 10"
246507 - 12"
246508 - 18"
246509 - 24"
