Connector Parts - My Child On Board Instruction Manual

Assembly - Readying the connectors for fitting

5. Connector parts:

(A) Tube protector.
(B) Block
(C) Body
(D) Quick release slider
(E) Strap
(F) Adjuster button
(G) Safety knob
(H) Tubing adapter (for square tubing)
6. To get the connectors ready for fitting on the pushchair, press the adjuster button (F)
and release the strap (E).
