- Page 1 Motor-drive Unit TAPMOTION® TD ISM® Operating Instructions 4489615/01 EN . OEM-Control-Box...
- Page 2 © All rights reserved by Maschinenfabrik Reinhausen Dissemination and reproduction of this document and use and disclosure of its content are strictly prohibited unless expressly permitted. Infringements will result in liability for compensation. All rights reserved in the event of the granting of patents, utility models or designs.
- Page 3 Table of contents Table of contents Introduction......................... 5 Validity..............................5 Manufacturer............................5 Subject to change without notice......................5 Supporting documents......................... 5 Safekeeping............................6 Notation conventions........................... 6 1.6.1 Symbols................................. 6 1.6.2 Hazard communication system..........................7 1.6.3 Information system..............................8 1.6.4 Instruction system..............................8 1.6.5 Typographic conventions............................
- Page 4 Table of contents Operation........................... 21 Maintenance and care....................... 22 Fault elimination........................ 23 Disposal..........................24 Technical data........................25 TAPMOTION® TD ISM® 4489615/01 EN Maschinenfabrik Reinhausen GmbH 2016...
- Page 5 1 Introduction Introduction This technical file contains detailed descriptions on the safe and proper in- stallation, connection, commissioning and monitoring of the product. It also includes safety instructions and general information about the prod- uct. This technical file is intended solely for specially trained and authorized per- sonnel.
- Page 6 1 Introduction Safekeeping This technical file and all supporting documents must be kept ready at hand and accessible for future use at all times. Notation conventions This section contains an overview of the symbols and textual emphasis used. 1.6.1 Symbols Symbol Meaning Wrench size...
- Page 7 1 Introduction Symbol Meaning Coupling bolt Use a ruler Use a saw Hose clip Wire eyelet, safety wire Use a screwdriver Table 1: Symbols 1.6.2 Hazard communication system Warnings in this technical file are displayed as follows. 1.6.2.1 Warning relating to section Warnings relating to sections refer to entire chapters or sections, sub-sec- tions or several paragraphs within this technical file.
- Page 8 1 Introduction Signal Meaning word DANGER Indicates a hazardous situation which, if not avoided, will result in death or serious injury. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. CAUTION Indicates a hazardous situation which, if not avoided, could result in injury.
- Page 9 1 Introduction Single-step instructions Instructions which consist of only a single process step are structured as fol- lows: Aim of action ü Requirements (optional). ► Step 1 of 1. ð Result of step (optional). ð Result of action (optional). Multi-step instructions Instructions which consist of several process steps are structured as follows: Aim of action ü...
- Page 10 2 Safety Safety General safety information The technical file contains detailed descriptions on the safe and proper in- stallation, connection, commissioning and monitoring of the product. ▪ Read this technical file through carefully to familiarize yourself with the product. ▪ Particular attention should be paid to the information given in this chap- ter.
- Page 11 2 Safety Personnel qualification The product is designed solely for use in electrical energy systems and facili- ties operated by appropriately trained staff. This staff comprises people who are familiar with the installation, assembly, commissioning and operation of such products. Operator's duty of care To prevent accidents, disruptions and damage as well as unacceptable ad- verse effects on the environment, those responsible for transport, installa-...
- Page 12 2 Safety Always wear Protective clothing Close-fitting work clothing with a low breaking strength, with tight sleeves and with no protruding parts. It mainly serves to protect the wearer against being caught by moving machine parts. Do not wear any rings, necklaces or other jewelry.
- Page 13 3 Product description Product description This chapter contains an overview of the design and function of the product. Scope of delivery The OEM Control Box is packaged with protection against moisture and is delivered as follows: ▪ OEM Control Box ▪...
- Page 14 3 Product description The OEM Control Box contains the following operating controls and display elements: Figure 2: Operating controls Motor protective switch In Position LED Error LED EMERGENCY OFF switch AUTO/MANUAL switch N key 1 key TAPMOTION® TD ISM® 4489615/01 EN Maschinenfabrik Reinhausen GmbH 2016...
- Page 15 4 Packaging, transport and storage Packaging, transport and storage Packaging The products are sometimes supplied with a sealed packaging and some- times also dried depending on what is required. A sealed packaging surrounds the packaged goods on all sides with plastic foil.
- Page 16 4 Packaging, transport and storage Transportation, receipt and handling of shipments Danger of death and damage to property! WARNING Danger of death and damage to property due to tipping or falling load! ► Transport crate only when closed. ► Do not remove the mounting material used in the crate during transport. ►...
- Page 17 4 Packaging, transport and storage changer/off-circuit tap-changer or contact Maschinenfabrik Reinhausen GmbH to agree on how to proceed with drying. If this is not done, the packaged goods may be damaged. ▪ Name the damaged parts. Hidden damage When damages are not determined until unpacking after receipt of the ship- ment (hidden damage), proceed as follows: ▪...
- Page 18 4 Packaging, transport and storage ▪ Unpack the packed goods and store in suitable storage space (well ven- tilated, as dust-free as possible, humidity < 50 % where possible). Unpacking shipments and checking for transportation damages NOTICE! ▪ Transport the packaged crate to the place where installation will take place.
- Page 19 5 Installation and commissioning Installation and commissioning This chapter describes how to correctly connect and commission the OEM Control Box. Risk of severe injury or death! WARNING An energized transformer and energized on-load tap-changer components can cause death or serious injuries when installing the motor-drive unit! ►...
- Page 20 5 Installation and commissioning Configure motor protective switch according to the gear motor's rated current and tripping class. To do so, note the table below. Figure 3: Configuring motor protective switch Rated current and tripping class of the gear motor Motor designation CLASS 380 V...
- Page 21 6 Operation Operation You can control the TAPMOTION® TD ISM® motor-drive unit's gear motor using the OEM Control Box in two different operating modes: ▪ MANUAL: In MANUAL mode, the gear motor only runs as long as key 1 or N is pressed and held down. This allows you to move the gear motor incrementally.
- Page 22 7 Maintenance and care Maintenance and care You can clean the device's housing with a dry cloth. TAPMOTION® TD ISM® 4489615/01 EN Maschinenfabrik Reinhausen GmbH 2016...
- Page 23 Contact Maschinenfabrik Reinhausen. Table 9: Fault elimination Other faults In the event of faults that cannot be easily corrected on site, please inform your authorized MR representative or contact us directly: Maschinenfabrik Reinhausen GmbH Technical Service Postfach 12 03 60...
- Page 24 9 Disposal Disposal The device was produced in accordance with European Community Direc- tive 2011/65/EC (RoHS) and must be disposed of accordingly. If the device is not operated within the European Union, the national disposal require- ments applicable in the country of use should be observed. TAPMOTION®...
- Page 25 10 Technical data Technical data Dimensions and weight Dimensions (W x H x D) 265 x 315 x 198 mm Weight 1.7 kg Table 10: Dimensions and weight Electrical connection loads Power supply 400 VAC Frequency 50/60 Hz Power consumption approx.
