12 TRANSMISSION LINE VOLUMES
The tables below contain estimated volume per
linear unit for the most common transmission
lines.
RFS Elliptical Waveguide volumes:
Waveguide Liters per
Type meter (l/m)
E38 2.58
E46 1.83
E60 1.05
E65 0.840
EP70 0.718
E78 0.590
EP100 0.368
E105 0.292
E130 0.212
E150 0.153
E185 0.0797
E220 0.0543
E250 0.0374
E300 0.0236
EO38 0.0636
E380 0.0130
RFS Air Dielectric Coaxial cable volumes:
Cable Liters per
Type meter (l/m)
HCA38 0.107
HCA12 0.134
ICA12 0.131
HCA58 0.252
HCA78 0.447
HCA118 0.753
HCA158 1.43
HCA214 2.11
HCA295 2.91
HCA300 3.44
HCA400 4.79
HCA495 7.79
HCA550 12.86
HCA618 17.09
HCA800 30.15
HCA900 40.16
Page 23 of 24
Cubic foot per
3
foot (ft /ft)
0.0275
0.0196
0.0113
0.00904
0.00773
0.00635
0.00396
0.00314
0.00229
0.00165
0.000858
0.000585
0.000403
0.000255
0.000685
0.000140
Cubic foot per
3
foot (ft /ft)
0.00115
0.00144
0.00142
0.00272
0.00481
0.00810
0.0154
0.0227
0.0313
0.0371
0.0516
0.0839
0.138
0.184
0.325
0.432
Commscope/Andrew Elliptical Waveguide
volumes:
Waveguide
Type
EW17
EW20
EW37
EW43
EW52
EW63
EW64
EW77
EW85
EW90
EW127A
EW132-137
EW132-140
EW132-144
EIA Rectangular Waveguide (TE10 mode)
Volumes:
Waveguide
Type
WR340 / WG9A
WR284 / WG10
WR229 / WG11A
WR187 / WG12
WR159 / WG13
WR137 / WG14
WR112 / WG15
WR90 / WG16
WR75 / WG17
WR62 / WG18
WR51 / WG19
WR42 / WG20
WR28 / WG22
WR22 / WG23
WR19 / WG24
WR15 / WG25
WR12 / WG26
Rigid Coaxial Transmission Line (50‐ohm)
volumes:
Line
Size
7/8"
1-5/8"
3-1/8"
4-1/16"
6-1/8"
7-3/16"
8-3/16"
9-3/16"
602400011500
Revision C
Liters per Cubic foot per
3
meter (l/m) foot (ft /ft)
6.60 0.0710
5.62 0.0605
1.96 0.0211
1.69 0.0182
1.045 0.0112
0.855 0.0092
0.725 0.0078
0.585 0.0063
0.39 0.0042
0.334 0.0036
0.25 0.0027
0.167 0.0018
0.167 0.0018
0.167 0.0018
Liters per Cubic foot per
3
meter (l/m) foot (ft /ft)
3.73 0.0401
2.46 0.0264
1.70 0.0183
1.05 0.0113
0.816 0.00878
0.551 0.00593
0.360 0.00387
0.232 0.00250
0.181 0.00195
0.125 0.00134
0.0839 0.000903
0.0461 0.000496
0.0253 0.000272
0.0162 0.000174
0.0114 0.000123
0.00707 0.0000761
0.00480 0.0000517
Liters per Cubic foot per
3
meter (l/m) foot (ft /ft)
0.255 0.0027
0.958 0.0103
3.77 0.0405
6.36 0.0685
14.70 0.158
22.80 0.245
29.77 0.320
33.30 0.358
