1
Part No.
1
Lock Assembly
2
Code Card
3
Fixing Bolts Washers
4
Fixing Bolts
5
Fixing Bolt Sleeves
6
Latch Bolt Sleeve
7
Hex Wrench
8
Push Label
9
Pull Label
Retrofit 140mm Centre Adaptor Plate (S331)
Part No.
10
Adaptor Plate
11
Adaptor Plate Fixing Screws
www.borglocks.com
BL3030ECP & BL3080ECP
Series Instruction Manual

Parts Lists

Code C####
5
PUSH
Description
10
Retrofit 140mm Centre Adaptor Plate
Helpline: +44 (0)1708 225700
2
3
6
8
BL3030 ECP BL3080 ECP
11
4
7
9
PULL
Model

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BL3030ECP and is the answer not in the manual?

Questions and answers

MARGARET Jeanette copson
April 15, 2025

Lock on one side is working ,the other side is not working

1 comments:
Mr. Anderson
April 15, 2025

If one side of the Borg Locks BL3030ECP is working but the other side is not, the issue could be due to incorrect installation, especially if the unit was not properly aligned or if the latch bolt was not correctly set during installation. It may also result from improper code setting or mechanical failure on the non-working side.

This answer is automatically generated

Summary of Contents for Borg Locks BL3030ECP

  • Page 1 BL3030ECP & BL3080ECP Series Instruction Manual Parts Lists Code C#### PUSH PULL Model Part No. Description BL3030 ECP BL3080 ECP Lock Assembly Code Card Fixing Bolts Washers Fixing Bolts Fixing Bolt Sleeves Latch Bolt Sleeve Hex Wrench Push Label Pull Label Retrofit 140mm Centre Adaptor Plate (S331) Part No.
  • Page 2 Preparation & Handing Please check that all the parts are working correctly. Enter the factory preset code as on the code card (Part No.2 ), rotate the knob way from the edge of the locking mechanism, ensuring that the knob rotates freely and retracts the latchbolt each time.
  • Page 3 Installation New Fit Installation Diagram Retro-fit Installation Diagram - W/ S331 Adaptor Plate...
  • Page 4 Code Change Instructions The code can be changed with the unit fitted on/off the gate. The unit is non sequential, therefore if the code is set to 1234, the keypad will open if entered 4321, 3214 etc..There are over 500 different code combinations available. The code should be changed with the door in the open position.
