9.3

AV3-PH PULL HITCH ASSEMBLY

REF. QTY.
1 1
2 1
3 2
4 1
5 1
6 1
7 2
28
PART NO. DESCRIPTION
AV3-PH-0100 Pull Hitch Weldment
P7103CL
Hitch Pin ¾ " x 5 ¾ "
HR-0177 Short Spacer for Tine Bars
B831 bushing ¾ " x 1 15⁄16"
SL-1541 Ratchet Jack
HR-0317 Clevis Pin 1"
HR-0634
Plastic Cap 2 ½ " Square
