7�- Technical Features - Circutor REC 3 Series Instruction Manual

REC 3 - REC 3C
7�- TECHNICAL FEATURES
Rated voltage
Tolerance
Frequency
Maximum power consumption
Installation category
Rated voltage
Rated current
Sensitivity, IΔn
Resistance to surges
Resistance to short-circuits
Class
Number of poles
Rated marking and brealing capacity
Working frequency
The leakage current will be supervised by measuring the resistance downstream of the RCCB.
Sensitivity
30 mA
300 mA
Type
Rated voltage
Maximum current
Nominal power
LEDs
Operating temperature
Storage temperature
Relative humidity (non-condensing)
Maximum altitude
Resistance to pollution
Protection degree
Instruction Manual
Power supply
RCCB
class A , AC: 250A 8/20μs
class S: 3000A 8/20μs
Inc : 10000A to 230/400V with gB 80A fuse
REC 3- REC 3C 2 poles
2
Measurement circuit
Rd and Rd0
Rd < 15 KΩ
Rd0 > 23 KΩ
Rd < 2.5 KΩ
Rd0 > 5.0 KΩ
Outputs (REC 3C models)
User interface
2 LEDs: AUTO in green and REC in red
Environmental features
230V
~
-15%, +15%
50Hz - 60Hz , ±5%
5VA
CAT III 300V
230V
~
40 / 63 A
30 mA or 300 mA
A (IEC 61008.1)
REC 3 - REC 3C 4 poles
4
Im : 500 A
50 / 60 HZ
RCCB response
no reclose
reclose
no reclose
reclose
2 switched contacts
230
~
0.13A
30 VA
-25ºC... +55ºC
- 35ºC... +65ºC
5 ... 95%
2000 m
Category 2
IP 20
23
