3.4
Display (optional)
• If you buy your evaluation kit with 8" or 10.1" panel, please refer to the separate 8" / 10.1" panel installation guide included with the panel for more details.
!
After you finish the panel installation, return to this guide.
Please follow the steps below to properly install the 5" display.
Step 1: Prepare evaluation board, MIPI expander board and screws.
Step 2: Locate the MIPI expander board and align the 70-pin connectors, gently press the connector on the back of the expander board onto the connector on the
evaluation board until you hear a click sound.
Step 3: Use three screws to secure the MIPI expander board to the development board.
Step 4: Locate the MIPI Display connectors on the expander board. Swivel the black retaining clips upward.
Step 5: Insert end of the TOUCH and MIPI Display FPC cables into the connectors on the board. The silver pins on the FPC cable should be facing down. Then swivel
the retaining clips back down to hold the FPC cables in place.
Step 6: Remove the protective transparent film from the display.
1
2
4
5
3.5
Final steps
Now your kit is almost assembled.
Step 1: Connect the RTC backup battery.
Step 2: Attach the extender cable to the Wi-Fi antenna.
Step 3: Connect the 2-pin Micro-Fit 3.0 cable to power up the evaluation kit.
1
2
3
3
6
3
4
Pin Definition
4.1
Power Connector (DCIN1 DCIN2)
This product features one 2-pin Micro-Fit 3.0 power connector: DCIN1 +12v.
DCIN1:
Header
Pin #
1
2
2
1
Header on PICO-WIZARD-IMX8M: Molex 43045-0212 (2-pin Micro-Fit 3.0).
Cable receptacle: Molex 43025-0200 (2-pin Micro-Fit 3.0) plug with crimp contact Molex 43030-0007.
4.2
SW3-8 Default Boot Mode Switches
The PICO-WIZARD-IMX8M features internal Default Boot Mode switches.
SW3-SW6:
Switch #
eMMC (default) MicroSD Serial Downloader
SW3
2-3
1-2
X
SW4
2-3
2-3
1-2
SW5
1-2
2-3
X
SW6
1-2
1-2
2-3
4.3
WI-FI Mode Setting
WI-FI
RJ11-RJ6
R488
R404
R470
R90
WI-FI
(1-2)
ADD
DEL
DEL
ADD
WO
(2-3)
DEL
ADD
ADD
DEL
WIFI
5
External Connectors
Front view:
21
20
19
18
17
22
23
24
25
26
27
28
29
30
31
1 2
4 5 6 7 8
9
10
11 12
3
No.
Description
No.
Description
1
SW3-SW6 switch
12
Power Input connector
2
L-Speaker connector
13
SW8 switch
3
R-Speaker connector
14
M.2 KEY-B connector
4
3.5mm jack audio out
15
PCIe connector
5
LAN RJ45 connector
16
MIPI Display connector
6
JP17-JP20 select jumper
17
J3-J5 jumper
7
USB OTG (Type-C) connector
18
J6 jumper
8
USB Host connectors (2x)
19
40-pin expansion header
HDMI connector
20
TOUCH1 connector
9
10
CAN Bus connector
21
NTAG1 connector
Reset1 button
MIPI Camera2 connector
11
22
6
Software Installation
The unit is preloaded with software that can download and install a selection of OS images over hardwired network. Simply connect a network to the unit through the LAN RJ45
connector and power it up, then follow the steps on the screen to load the software. Local proxies will interfere with this process. For more information, go to our Knowledge Base
at: https:/ /www.technexion.com/support/knowledge-base/
• All Rights Reserved. No part of this document may be photocopied, reproduced, stored in a retrieval system, or transmitted, in any form or by any means whether, electronic, mechanical, or otherwise
without the prior written permission of TechNexion Ltd.
• No warranty of accuracy is given concerning the contents of the information contained in this publication. To the extent permitted by law no liability (including liability to any person by reason of
negligence) will be accepted by TechNexion Ltd., its subsidiaries or employees for any direct or indirect loss or damage caused by omissions from or inaccuracies in this document.
• TechNexion Ltd. reserves the right to change details in this publication without notice. Please download the most updated version at: https:/ /www.technexion.com/support/download-center/
© 2001-2020 TechNexion Ltd.
16F-5, No. 736, Zhongzheng Road, ZhongHe District, 23511, New Taipei City, Taiwan
2020-09-21
Signal
Description
GND
Ground
VCC
DC Voltage input (12V DC)
SW7:
SW8:
ETH
SW7
I/O
SW8
1-8 2-7
IMX8M
3-6
2.5V
ENABLE
CANBUS1
ON
* SW7 is default without setting
TERMINATOR
RESISTOR
DISABLE
CANBUS1
OFF
TERMINATOR
RESISTOR
4.4
IMX8M BOOT Device Jumper Settings
J9
pin3
pin7
eMMC
Low
High
SD2
High
Low
Rear view:
16
32
15
33
14
13
No.
Description
23
MIPI Camera1 connector
24
VOICEHAT2 12-pin connector
25
LVDS1 connector
26
MicroSD card slot
27
CLIX2 hole15 connector
28
CLIX1 hole17 connector
SW7 switch
29
30
M1 Console
31
M4 Console
32
Micro-SIM1 card slot
Micro-SIM2 card slot
33
Phone: +886-2-82273585 Web: www.technexion.com
3-6 4-5
ENABLE
CANBUS2
TERMINATOR
RESISTOR
DISABLE
CANBUS2
TERMINATOR
RESISTOR
