- Page 1 INSTRUCTION MANUAL Electric Compact Circular Saw Model # PS4005 Have product questions or need technical support? Please feel free to contact us! Website: www.Amerisuninc.com Toll free: 1-800-791-9458 M-F 9-5 EST Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
18.1x4.9 x5.9 inches Weight: 5.7 lb. Thank you for purchasing Power Smart products. Please register online at www. Amerisuninc.com. The information will allow us to track your warranty and update on your unit. Important: Our company does not provide email or personal information to any third party for any reason. -
Page 4: General Safety Rules
GENERAL SAFETY RULES Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. SAVE ALL WARNINGS AND INSTRUCTIONS FOR FUTURE REFERENCE. WORK AREA SAFETY • Keep work area clean and well lit. Cluttered or dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, •... - Page 5 Definitions: Safety Alert Symbols and Words This instruction manual uses the following safety alert symbols and words to alert • you to hazardous situations and your risks of personal injury or property damage. • DANGER: Indicates an imminently hazardous situation which if not avoided, will result in death or serious injury.
- Page 6 WARNING: ALWAYS use safety glasses. Everyday eyeglasses are NOT safety glasses. Also use face or dust mask if cutting operation is dusty. ALWAYS WEAR CERTIFIED SAFETY EQUIPMENT: • WARNING: Some dust created by power sanding, sawing, grinding, drilling, and other construction •...
-
Page 7: Electrical Information
ELECTRICAL INFORMATION Guidelines for using extension cords When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating. The following table shows the correct size to use depending on cord length and nameplate ampere rating. -
Page 8: Knowing Your Electric Compact Circular Saw
KNOWING YOUR ELECTRIC COMPACT CIRCULAR SAW Fig 1 Fig 2... -
Page 9: Assembly Instruction
laser generator Edge guide locking screw Blade clamp screw Lower guard Unlock button Switch trigger Laser Spindle lock button Depth setting clamp Lower guard Lock lever knob for angle adjustment Dust extraction nozzle Saw blade Baseplate ASSEMBLY INSTRUCTION Check for damage to the tool, parts and accessories which may have occurred during transportation. Take some time to read this manual carefully and understand all the content prior to assembly and operation. - Page 10 6. Reinstall the outer flange, washer and tighten the blade clamp screw (3) by turning it counterclockwise with the wrench provided. 7. Make sure the saw blade (13) can turn freely by turning the blade by hand when release the spindle lock button.
-
Page 11: Operating Instruction
OPERATION INSTRUCTION Switching on and off Note: Before engaging the on/off switch, check the saw blade to see if it is fitted properly and runs smoothly, and the blade clamp screw is well tightened. Connect the plug to the power supply. ... - Page 12 Cutting large sheets Large sheet or boards require support to prevent bends or sags. If you attempt to cut without levelling and properly supporting the work piece, the blade will tend to bind, causing kickback. Support the panel or board close to the cut. Be sure to set the blade adjustment so that you can cut ...
-
Page 13: Maintenance
MAINTENANCE Warning: Do not at any time let brake fluids, gasoline, petroleum-based products, penetrating oils, etc., come in contact with plastic parts. Chemicals can damage, weaken or destroy plastic which may result in serious personal injury. Regular cleaning is required for the safe operation of the tool, as an excessive buildup of dust will prevent the tool from operating correctly. -
Page 14: Exploded View
EXPLODED VIEW... -
Page 15: Parts List
PARTS LIST Item Stock# Description Item Stock# Description PS4005-001 laser cover PS4005-041 saw blade PS4005-002 spring holder PS4005-042 outer flange PS4005-003 tower type spring PS4005-043 saw blade forcing screw M6*!4 PS4005-004 button cell PS4005-044 spring PS4005-005 ST4.2x12 Cross head screw PS4005-045 lower guard lever PS4005-006... -
Page 16: Warranty
TWO (2) YEARS LIMITED WARRANTY OF POWER SMART PRODUCTS FOR HOME USE. Power Smart (“Seller") warrants to the original purchaser only, that all Power Smart consumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase. Ninety (90) days for all Power Smart Products, if the tool is used for professional or commercial use.
