- Page 1 9236061 INSTALLATION INSTRUCTION 21 IN. UNDERMOUNT RUNNER Questions, problems, missing parts? Before returning to the store, call Everbilt Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-305-1726 HOMEDEPOT.COM THANK YOU...
-
Page 2: Table Of Contents
Manufacturer’s option, refund the purchase price. Repair, replacement, or refund of the original purchase price is your sole remedy under this or any other warranty on the product, whether expressed or implied. For additional details and questions, please contact Everbilt Customer Service at 1-800-305-1726. -
Page 3: Installation Options
Installation Options Is this the right drawer for my project? Please check the following points Drawer dimensions need to be met to fit slides Fits 21 in. deep drawers These slides can be installed in frameless and face frame cabinetry. Instructions for both options are provided in this manual The drawer side thickness must be 1/2 in. -
Page 4: Pre-Installation
Pre-Installation PLANNING INSTALLATION Ensure all parts listed in the Package Contents section are included and that you have the listed Tools and Materials Required on hand. TOOLS REQUIRED Phillips Pencil Drill with Measuring Tape screwdriver 3/32“ Drill bit for screws 1/4“... -
Page 5: Dimensions
Dimensions Please review these diagrams and measure and mark your installation location before you begin the installation procedures. CABINETRY DIMENSIONS DRAWER DIMENSIONS Drawer side thickness 1/2" (13 mm) or 5/8" (16 mm) Inside cabinet width (ICW) Outside drawer width Inside drawer width 1-3/16"... -
Page 6: Face Frame Installation
Face Frame Installation Preparing the slides A /B Slide plastic connector from rear bracket into the notch on the left and right drawer slides (A and B) forward, as shown. Face frame application Cabinet front edge 3/8“ (10 mm) Setback 3/32“ (2 mm) Front gap 1/16“... -
Page 7: Metal Rear Attachment Set (Screw-On)
Face Frame Installation Metal rear attachment set (screw-on) Set contains 2 metal rear mount rackets and 2 plastic connectors Non-handed, two-piece design For up to 50 mm (1 15/16“) depth adjustment and ± 1,5 mm (1/16“) side adjustment Additional adjustment via oblong holes Installation recommended with min. -
Page 8: Frameless Installation
Frameless Installation Frameless application Cabinet front edge 1 7/16“ (37 mm) Min. 5/8“ (16 mm) 3/8“ (10 mm) Setback 3/32“ (2 mm) Front gap 1/16“ (1.5 mm) Frameless application with overlay decorative front Minimum cabinet depth (see below) Inset application increases minimum cabinet depth by thickness of decorative front. -
Page 9: Drawer Installation And Removal
Drawer Installation and Removal Installing the drawer catches Install each drawer catch (C) into the two front corners of the drawer using #6 x 3/4 in. screws (H) or #6 x 1 in. screws (I). If you need to install the screws at an angle, do not angle the screws more than 30°. If your door subfront is 1/2 in. (13 mm) use the optional spaces (D). DRAWER CATCH DIMENSIONS 26 mm (1-1/32") - Page 10 Questions, problems, missing parts? Before returning to the store, call Everbilt Customer Service 8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday 1-800-305-1726 HOMEDEPOT.COM Retain this manual for future use.
