- Page 1 RedEdge-MX™ & Altum™ DJI M200 Series Quick Mount G en. 2 INTEGRATION GUIDE Rev 01 - July 2019 P/N: 805-00055 ...
-
Page 2: Table Of Contents
Attaching DLS 2 mast assembly 3 RedEdge-MX Instructions 5 Attaching the RedEdge-MX and the Mount 5 Attaching the RedEdge-MX and DLS 2 to the M atrice 6 Altum Instructions 6 Attaching the Altum and the Mount 6 Attaching the Altum and DLS 2 to the M atrice 7 ... -
Page 3: Thank You For Your Purchase
Thank you for your purchase! These instructions show how to integrate the MicaSense RedEdge-MX and/or Altum with a DJI M200 Series (V1 & V2). It covers attaching mounting brackets included in the kit, powering the camera from the host system, and placement of the Downwelling Light Sensor (DLS 2) unit. ... -
Page 4: What's Required
What’s Required? ● #1 Phillips Screwdriver ● Cutting tool - such as scissors or diagonal cutter ● 1.5 mm hex wrench ● 2 mm hex wrench Let’s get started! Warning: Installation of this kit into a drone should be done by an experienced person, in adherence with all recommendations and guidelines of the drone ... - Page 5 DLS2 or contact with the mast . Warning: Failure to properly secure loose wires may lead to interference with the aircraft propellers. This may damage the Matrice, RedEdge-MX/Altum, or both. Rev 01 - August 2019 PAGE 4 ...
-
Page 6: Rededge-Mx Instructions
1. Locate the two M3 x 6 mm socket head cap screws, M3 lock washers, and Quick Mount Gen. 2 Adapter. 2. Using the counterbore screw holes, attach the mount to the back of the RedEdge-MX. Make sure the mount 8-pin camera port is located on the same side as the camera ... -
Page 7: Attaching The Rededge-Mx And Dls 2 To The Matrice
DJI lock mechanism on the Inspire. 2. Use the provided 6-pin 60cm cable to connect the DLS2 and the RedEdge-MX. Plug the DLS 2 cable from the DLS 2 port to the Quick Mount Gen. 2 “6-pin DLS” port. ... -
Page 8: Attaching The Altum And Dls 2 To The Matrice
3. When attached, the camera will be tilted forward slightly to compensate for the tilt of the aircraft while flying. Warning: Failure to properly secure loose wires may lead to interference with the aircraft propellers. This may damage the Matrice, RedEdge-MX/Altum, or both. Rev 01 - August 2019 PAGE 7 ... -
Page 9: Support
MicaSense RedEdge-MX & Altum Quick Mount Gen. 2 for DJI Matrice 200 Series Instructions. The contents of this manual are subject to change without notice. MicaSense, Inc. assumes no liability for incidental or consequential damages arising from the ... - Page 10 PROCESS With MicaSense sensors, you own your data. You’re not limited to a particular processing platform. You can choose whichever platform is best for you, your customer, or your project. ...
- Page 11 Located in Seattle, Washington, MicaSense delivers integrated solutions for data gathering, processing, and analytics across the global agriculture market. With decades of expertise in widely varied UAV applications, the MicaSense team is redefining remote sensing technology and pioneering new ways to collect and analyze information. ...
- Page 12 Revision History Revision Description Date 01 Initial Release 13 Aug 2019 Rev 01 - August 2019 PAGE 11 ...
