Quantum Design KuDoz 7X Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Item Checklist
Notice
www.qdigrp.com
1
02-9-10, 11:40
KD7Xen1.p65

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KuDoz 7X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Quantum Design KuDoz 7X

Summary of Contents for Quantum Design KuDoz 7X

  • Page 1 Item Checklist Notice www.qdigrp.com 02-9-10, 11:40 KD7Xen1.p65...

  • Page 2: Declaration Of Conformity

    Declaration of conformity QUANTUM DESIGNS(HK) LTD. 20th Floor, Devon House, Taikoo Place, 979 King’s Road, Quarry Bay, Hong Kong declares that the product Mainboard KD7X is in conformity with (reference to the specification under which conformity is declared in accordance with 89/336 EEC-EMC Directive) EN 55022 Limits and methods of measurements of radio disturbance "...
  • Page 3 Declaration of conformity Trade Name: QDI Computer ( U. S . A. ) Inc. Model Name: KD7X Responsible Party: QDI Computer ( U. S. A.) Inc. Address: 41456 Christy Street Fremont, CA 94538 Telephone: (510) 668-4933 Facsimile: (510) 668-4966 Equipment Classification: FCC Class B Subassembly Type of Product: Mainboard...
  • Page 4 CONTENTS Chapter 1 ............. 1 Chapter 2 ............. 5 02-9-10, 11:40 KD7Xen1.p65...
  • Page 5 Chapter 3 ............23 Appendix ............48 02-9-10, 11:40 KD7Xen1.p65...
  • Page 6 Caution Be sure to add some Silicone Grease between the CPU and the heatsink of FAN to keep them fully contact , meanwhile to meet the heat sink requirement. Caution Be sure to add some Silicone Grease between the CPU and the heatsink to keep them fully contacted to meet the heat sink requirement.
  • Page 7 This manual is suitable for mainboards of KuDoz 7X series. Each mainboard is carefully designed for the PC user who wants di- verse features. with onboard Audio -6A: with 6 channel Audio with onboard LAN 02-9-10, 11:40 KD7Xen1.p65...
  • Page 8 02-9-10, 11:40 KD7Xen1.p65...
  • Page 9 Chapter 1 Chapter 1 Introduction KuDoz 7X KuDoz 7X 02-9-10, 11:40 KD7Xen2.p65...

  • Page 10: Key Features

    Introduction Key Features Form factor Microprocessor System memory Graphics Onboard IDE 6 USB USB 2.0 Onboard LAN 02-9-10, 11:40 KD7Xen2.p65...
  • Page 11 Chapter 1 Onboard Audio Onboard I/O ² ² BIOS Green function Expansion slots KuDoz 7X 02-9-10, 11:40 KD7Xen2.p65...

  • Page 12: Advanced Features

    Introduction Advanced features Note: Our technology is now being upgraded, the description and Interface for Easy technology in this manual are only for your reference. If you would like to get the upgraded version, please download the latest BIOS or the utility from the website to re-flash your mainboard;...

  • Page 13: Installation Instructions

    Chapter 2 Chapter 2 Installation Instructions KuDoz 7X 02-9-10, 11:40 KD7Xen2.p65...

  • Page 14: External Connectors

    Installation Instructions External Connectors PS/2 Keyboard/Mouse Connector USB1, USB2 and LAN Connectors Warning: Be sure to unplug the AC power supply before adding or remov- ing expansion cards or other system peripherals, otherwise your mainboard and expansion cards might be seriously damaged.
  • Page 15 Chapter 2 Line-in jack, Microphone-in jack, Speaker-out jack and MIDI/Joystick Con- nector 6-Channel Audio Front Center&Woofer Back Left&Right Left&Right Parallel and Serial Ports KuDoz 7X 02-9-10, 11:40 KD7Xen2.p65...
  • Page 16 Installation Instructions ATX Power Supply Connector & Power Switch (POWER SW) Push once ATX Power 3.3V 3.3V GND 5V GND PS-OK 5VSB 3.3V -12V PS-ON POWER SW Note: If you change “Soft-off by PWR-BTTN” from default “Instant- off” to “Delay 4 Sec” in the “POWER MANAGEMENT SETUP” section of the BIOS, the power switch should be pressed for morethan 4 seconds before the system powers down.
  • Page 17 Speaker Connector (SPEAKER) Power LED Connector (PWR LED) GREEN LED Connector (GREEN LED) HD_LED HDD LED(+) HDD LED(-) ORANGE(-) GREEN(-) LED+(VCC) POWER SPKDATA RESET EMPTY EMPTY EMPTY LED+ SLEEP LED- LED- LED+ LED- LED- KEYLOCK KuDoz 7X 02-9-10, 11:41 KD7Xen2.p65...
  • Page 18 Installation Instructions ACPI LED Connector (ACPI LED) Hardware Green Connector (SLEEP SW) Smart Card Reader Connector( SCR )(Optional) SCPSNT SCPWCTL# SCIO SCCLK SCRST# 02-9-10, 11:41 KD7Xen2.p65...
  • Page 19 Chapter 2 Front panel USB2 and USB3 Connectors USB2 USB3 S/PDIF Output Connector(SPDIF)(Optional) SPDIF out SPDIF Output KuDoz 7X 02-9-10, 11:41 KD7Xen2.p65...

  • Page 20: Infrared Header (Irda)

    Installation Instructions Infrared Header (IrDA) IrDA Connector Audio Connectors (CD_IN, AUX_IN, MODEM)(Optional) CD Right Channel CD_IN Common CD Left Channel Right Channel AUX_IN Common Left Channel Phone-In (from Modem) Modem Mono-Out (to Modem) 02-9-10, 11:41 KD7Xen2.p65...
  • Page 21 Chapter 2 Fan Connectors ( CPUFAN, CHIPFAN, SYS_FAN) CHIP_FAN CPU_FAN FAN GND +12V SENSE SYS_FAN(optional) FAN GND +12V SENSE Front panel 6 Channel Connector( J8 )(Optional) SRout_L Center_out SRout_R LFE_out SPDIF_out KuDoz 7X 02-9-10, 11:41 KD7Xen2.p65...
  • Page 22 Installation Instructions Wake-Up On LAN (WOL) +5VSB Signal for waking up Wake-Up On Internal Modem (WOM) +5V standby Signal for waking up 02-9-10, 11:41 KD7Xen2.p65...
  • Page 23 Audio Interface (F_AUDIO)(Optional) Microphone in Line in Speaker FrontLineOutR Speaker Out (Active Audio) LineNextR LineNextL FrontLineOutL Front Audio jack Earphone (Front Audio) F_AUDIO i t c i t c ( t x ( t x KuDoz 7X 02-9-10, 11:41 KD7Xen2.p65...

  • Page 24: Jumper Settings

    Installation Instructions Jumper Settings Jumper Symbol Description Represent Clear CMOS (CLR_CMOS) CLR_CMOS Normal status: Clear CMOS: (Unplug the AC power supply ) 02-9-10, 11:41 KD7Xen2.p65...
  • Page 25 Chapter 2 BIOS Protection Jumper (BIOS_WP) Flash Write Disabled Flash Write Enabled BIOS_WP CPU Bus Ratio Selection (JFID) JFID KuDoz 7X 02-9-10, 11:41 KD7Xen2.p65...
  • Page 26 Installation Instructions CPU Bus Ratio Setting (J4, J9) & & & & & & & & Note: Warning: 02-9-10, 11:41 KD7Xen2.p65...
  • Page 27 Chapter 2 Enable/Disable Onboard Audio(JP1, JP2, JP3) Jumper for CPU temperature setting( J7 )(optional) Athlon XP CPU Others KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 28 Installation Instructions Enable/Disable Onboard LAN( JLAN ) Enable onboard LAN: (Default) Disable onboard LAN: JLAN SCR/Floppy B Selection (J5, J6) Enable SCR Disable Floppy B Disable SCR Enable Floppy B ( default ) 02-9-10, 11:42 KD7Xen2.p65...
  • Page 29 Chapter 2 Overclocking Jumper Setting (JFSB1 and JFSB2) JFSB1 JFSB2 Warning: Be sure your selection is right. CPU over speed will be dangerous! We will not be responsible for any damages caused. KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 30 Installation Instructions Main Expansion Slots and Connectors Slot/Port (Quantity) Description 02-9-10, 11:42 KD7Xen2.p65...

  • Page 31: Bios Description

    Chapter 3 Chapter 3 BIOS Description KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...

  • Page 32: Utility Support

    BIOS Description Utility Support AWDFLASH.EXE Follow the steps exactly for a successful upgrade. Note: 1. Follow the instruction through the process. Don’t turn off power or reset the system until the BIOS upgrade has been completed. 2. AWDFLASH.EXE (version>=8.03) utility must be used to upgrade the mainboard family BIOS instead of QDI flash utility.

  • Page 33: Entering Setup

    Chapter 3 AWARD(Phoenix) BIOS Description Entering Setup Press <Del> to enter SETUP Figure-1 Main Menu Load Fail-Safe Defaults Load Optimized Defaults Standard CMOS Features Setup KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 34 BIOS Description Figure-2 Standard CMOS Setup Menu Figure-2-1 IDE Primary Master Setup Menu Hard Disk Primary Master/Primary Slave/Secondary Master/Secondary Slave HDD access mode 02-9-10, 11:42 KD7Xen2.p65...
  • Page 35 Chapter 3 CHS mode LBA (Logical Block Addressing) mode Large mode Remark KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 36 BIOS Description Video Halt On Memory 02-9-10, 11:42 KD7Xen2.p65...
  • Page 37 Chapter 3 QDI Innovation features Figure-3 QDI Innovation features Menu Item Option Description [SpeedEasy setting] Enabled Disabled +/-0.25% -0.5% Disabled Default 100/33MHz 150/38MHz [BootEasy setting] Enabled Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 38 BIOS Description Item Option Description [LogoEasyII setting] Enabled Disabled [RecoveryEasyII setting] English Chinese NULL F2~F12 [BIOS -protectEasy setting] Enabled Disabled Warning: Be sure your selection is right. CPU over speed will be dangerous! We will not be responsible for any damages caused.

  • Page 39: Advanced Bios Features Setup

    Chapter 3 Advanced BIOS Features Setup Figure-4 Advanced BIOS Features Menu Item Option Description Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 40 BIOS Description Item Option Description Enabled Disabled Disabled Floppy/ LS120 CDROM Enabled Disabled Enabled Disabled Normal Fast Enabled Disabled 6-30 250-1000 Setup System 02-9-10, 11:42 KD7Xen2.p65...
  • Page 41 Chapter 3 Item Option Description Enabled Disabled Non-OS2 Enabled Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...

  • Page 42: Advanced Chipset Features Setup

    BIOS Description Advanced Chipset Features Setup Figure-5 Advanced Chipset Features Menu Item Option Description Press Enter 100/133MHz 166/200MHz 100/133 166/200 By SPD By SPD Manual Turbo Ultra 2/3/4 Level 02-9-10, 11:42 KD7Xen2.p65...
  • Page 43 Chapter 3 Item Option Description 2T/3T 1T/2T 4/8/16/32 ...256MB Auto Manual 00-FF Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled Enabled Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 44 BIOS Description Item Option Description Enabled Disabled Enabled Disabled 15M-16M Disabled Enabled Disabled Enabled Disabled 02-9-10, 11:42 KD7Xen2.p65...

  • Page 45: Power Management Setup

    Chapter 3 Power Management Setup Figure-6 Power Management Setup Menu Item Option Description Enabled Disabled S1&S3 Disabled 1Min KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 46 BIOS Description Item Option Description Suspend->Off Always On Blank Screen V / H SYNC + Blank DPMS Note: When the green monitor does not detect the V/H-SYNC signals, the electron gun will be turned off. 3,4,5,7,9, 10,11 Instant-Off Delay 4 sec Auto Off,On Auto...
  • Page 47 Chapter 3 Item Option Description LPT, COM LPT/COM None Enabled Disabled Enabled Disabled Enabled Disabled Press Enter KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 48 BIOS Description Item Option Description Enabled Disabled 02-9-10, 11:42 KD7Xen2.p65...

  • Page 49: Pnp/Pci Configuration Setup

    Chapter 3 PNP/PCI Configuration Setup Figure-7 PNP/PCI Configuration Setup Menu Item Option Description Enabled Disabled Manual Auto(ESCD) Enabled Disabled Enabled Disabled Enabled Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...

  • Page 50: Integrated Peripherals

    BIOS Description Integrated Peripherals Figure-8 Integrated Peripherals Menu Item Option Description Enabled Disabled Press Enter Enabled Disabled Enabled Disabled Mode 0 ~ 4 Auto Auto Disabled Press Enter 02-9-10, 11:42 KD7Xen2.p65...
  • Page 51 Chapter 3 Item Option Description Auto Disabled Auto Disabled Enabled Disabled 3F8/IRQ4 2F8/IRQ3 3E8/IRQ4 Auto Disabled Normal IrDA ASKIR Full Half 378/IRQ7 278/IRQ5 3BC/IRQ7 Disabled EPP,ECP ECP+EPP 1, 3 KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 52 BIOS Description Item Option Description 201/209 Disabled 300/330 Disabled 5,10 PCI Slot All Enabled All Disabled 1&2/2&3/1&3 USB Port 1/2/3USB Port Enabled Disabled Enabled Disabled 02-9-10, 11:42 KD7Xen2.p65...

  • Page 53: Pc Health Status

    Chapter 3 PC Health Status Figure-9 PC Health Status Menu Item Option Description 60~85 Disabled KuDoz 7X 02-9-10, 11:42 KD7Xen2.p65...
  • Page 54 BIOS Description Item Option Description C~90 02-9-10, 11:43 KD7Xen2.p65...

  • Page 55: Password Setting

    Chapter 3 Password Setting ENTER PASSWORD PASSWORD DISABLED System Setup Boot with BIOS defaults KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...

  • Page 56: Norton Antivirus

    QDI Utility CD Appendix QDI Utility CD 1. Driver Install 2. Accessory 3. Browse CD Utility Documents Norton AntiVirus http://www.symantec.com/techsupp/tutorial 02-9-10, 11:43 KD7Xen2.p65...
  • Page 57 QDI Innovations LogoEasy II ------ Support x ------- Not Support LogoEasy II KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 58 Appendix A. Using CBLOGO.EXE Utility (Under DOS ): B. Using QFlash (Under Windows ): Note: 1. If you require more parameters information concerning “CBLOGO.EXE”, please refer to the online help. If you don’t prefer the logo displayed on the screen during bootup, set the “Show Bootup Logo”...
  • Page 59 QDI Innovations RecoveryEasy II Introduction: Features: Secure Backup Ease to Operate Adavantage Function Flexible Combination KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 60 Appendix Backup Backup content Restore content Partition Table Partition Table Partition Table System Partition System Partition+Partition Table System Partition, PartitionTable Whole Disk All Partitions+Partition Table System Partition, PartitionTable, Whole Disk CMOS Setup CMOS Setup CMOS Setup Menu Language and Hotkey Selection Menu language Select Hot key for Backup 02-9-10, 11:43...
  • Page 61 Hard Disk Select Backup Function Introduction 1 Backup Partition Table 2 Backup System Partition C: 3 Backup Whole Disk 4 Backup CMOS Setup 5 Free Backup Area 6 Exit Backup Menu figure-3 Backup Interface KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 62 Appendix 1 Backup Partition Table 2 Backup System Partition 3 Backup Whole Disk 4 Backup CMOS Setup 5 Release Backup Area 6 Exit Backup Menu figure-4 Backup process Recovery Function Introduction 02-9-10, 11:43 KD7Xen2.p65...
  • Page 63 2 Recover System Partition 3 Recover Whole Disk 4 Recover CMOS Setup 5 Exit Backup Menu figure-5 Recover Interface 1.Recover Partition Table 2.Recover System Partition 3.Recover Whole Disk 4.Recover CMOS Setup 5 Exit Recovery Menu figure-4 Recover process KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 64 Appendix SpeedEasy Procedures: CPU SpeedEasy Setup Menu QDI Innovation features Menu Warning: Do not set CPU frequency higher than its working frequency. If you do, we will not be responsible for any damages caused. 02-9-10, 11:43 KD7Xen2.p65...
  • Page 65 Setting the jumper BIOS_WP as open if you encounter the vabove conditions. Don’t power off or reset system while BootEasy initializing. Set “QDI BootEasy Feature” as “Disabled” before you replace system equipment. Set “QDI BootEasy Feature” as “Enabled” after you accomplished replacing. KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 66 Appendix BIOS-ProtectEasy 02-9-10, 11:43 KD7Xen2.p65...
  • Page 67 Appendix QDI BootEasy(German) BootEasy Setup Menu KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 68 Appendix Instalación de la placa base Legend-QDI KD7X(Spanish): 02-9-10, 11:43 KD7Xen2.p65...

  • Page 69: Instalación Del Sistema

    Appendix Instalación del sistema: Un disco compacto con controladores de Legend-QDI esta incluido en el paquete de la placa base Legend-QDI KD7X. 1. Instalación de los controladores KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 70 Appendix (Opcional) (Opcional) (Opcional) 2. Accessorios 3. Navegue por el CD Utility 02-9-10, 11:43 KD7Xen2.p65...
  • Page 71 Appendix Manuel d’installation des cartes mères de la série Legend-QDI KD7X  (French): Intégration du système : KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 72 Appendix 02-9-10, 11:43 KD7Xen2.p65...

  • Page 73: Installation Du Système

    Appendix Installation du système : Lors de son achat un CD-ROM d’installation Legend-QDI est livré avec la carte mère de la série Legend-QDI KuDoz 7X. Driver Install : KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 74 Appendix Accessory : Browse CD : 02-9-10, 11:43 KD7Xen2.p65...
  • Page 75 Appendix Legend-QDI KD7X installazione mainboard (Italian): protectEasy; KuDoz 7X 02-9-10, 11:43 KD7Xen2.p65...
  • Page 76 Appendix Installazione di sistema IL CD CONTENENTE I DRIVER DELLA VOSTRA MAINBOARD LEGEND-QDI E’ CONTENUTO NELLA SCATOLA Installazione driver 02-9-10, 11:44 KD7Xen2.p65...
  • Page 77 Appendix KuDoz 7X 02-9-10, 11:44 KD7Xen2.p65...

  • Page 78: Using 6-Channel Audio

    Appendix Using 6-Channel Audio Installing the Audio Driver Attaching speakers 02-9-10, 11:44 KD7Xen2.p65...
  • Page 79 Appendix Selecting 6-Channel Setting KuDoz 7X 02-9-10, 11:44 KD7Xen2.p65...
  • Page 80 Appendix 02-9-10, 11:44 KD7Xen2.p65...
  • Page 81 Appendix KuDoz 7X 02-9-10, 11:44 KD7Xen2.p65...
  • Page 82 Appendix Board Layout of KuDoz 7X This layout is just for your reference 02-9-10, 11:44 KD7Xen2.p65...
