- Page 1 Air Quality Sensor Z-Wave Plus Installation & Operation Guide Made in Germany www.eurotronic.org...
-
Page 2: Table Of Contents
Content Included in delivery Association Safety Instructions Configuration Intended Use Multilevel Sensor Product description Notification Operating the device Troubleshooting Button LEDs Cleaning Network behavior Technical specifications Power supply Add to a Z-Wave network (Inclusion) Disposal Remove from a Z-Wave network (Exclusion) 8 Factory reset Warranty Z-Wave... -
Page 3: Included In Delivery
1. Included in delivery 1 x Air Quality Sensor Z-Wave Plus 1 x Micro USB power supply 1 x Quick Start Manual NOTE! The following figures are for illustration purposes only and may differ from the actual product. Air Quality Sensor Z-Wave Plus Quick Start Manual Micro USB power supply NOTE! Please check the scope of delivery for completeness and intactness. -
Page 4: Safety Instructions
2. Safety Instructions Avoid potential dangers by reading the following safety instructions carefully. SAFETY INSTRUCTIONS - Air Quality Sensor Z-Wave Plus is designed for use in buildings. - Operate Air Quality Sensor Z-Wave Plus only as described in the user manual. - Air Quality Sensor Z-Wave Plus should only be put to use in a dry and dust-free place, away from direct sunlight. -
Page 5: Product Description
4. Product description The brand new Z-Wave sensor in an ultra slim design housing provides comprehensive information on indoor air quality. Based on these information it is possible to always ensure a healthy living climate. • Ultra-flat design housing • Use of high-precision, Swiss sensor technology •... -
Page 6: Operating The Device
5. Operating the device Button Button Interaction Result/Behavior Network press three times Air Quality Sensor Z-Wave Plus will react to inclusion or exclusion within 1 second commands. Network hold for 10 seconds Factory resets the Air Quality Sensor Z-Wave Plus. LEDs LED-Anzeige Color... -
Page 7: Network Behavior
6. Network behavior On factory default the device does not belong to Interoperability any Z-Wave network Air Quality Sensor Z-Wave This product can be operated in any Z-Wave Plus needs to be added to an existing wireless network with other Z-Wave certified devices from network to communicate with the devices of this other manufacturers. -
Page 8: Power Supply
Power supply Connect the Micro-USB cable to a AC adapter and to the air quality sensor and afterwards to a power outlet. Add Air Quality Sensor Z-Wave Plus to a Z-Wave network Start inclusion mode of your primary Z-Wave Controller. Press the network button three times within 1 second. -
Page 9: Factory Reset
Factory reset Press and hold the network button for at least 10 seconds. The Air Quality Sensor Z-Wave Plus will indicate the reset blinking pattern once the reset is completed. Please use this procedure only when the network primary controller is missing or otherwise inoperable. 7. -
Page 10: Association
8. Association Air Quality Sensor Z-Wave Plus can be associated with other devices. Group No. Description Commands Max supported Nodes Lifeline DEVICE_RESET_LOCALLY_NOTIFICATION, NOTIFICATION_REPORT, SENSOR_MULTILEVEL_REPORT, Temperature SENSOR_MULTILEVEL_REPORT 9. Configuration Air Quality Sensor Z-Wave Plus can be configured during runtime. Paramter Size Name Description number... -
Page 11: Multilevel Sensor
10. Multilevel Sensor Air Quality Sensor Z-Wave Plus measures the room temperature and automatically reports sensor readings to associated devices. Per default the reporting threshold is ±0.5°C. This parameter can be altered via configura- tion command class. Sensor type: „Air Temperature“ Celsius and Fahrenheit Scale: Precision:... -
Page 12: Troubleshooting
12. Troubleshooting Problem Reason Solution • Z-Wave Controller out of range. red LED lights A task has failed. • Repeat the task as needed. constantly for 5 seconds 13. Cleaning NOTE: RISK OF DAMAGE! Improper handling of the Air Quality Sensor Z-Wave Plus can lead to damage. -
Page 13: Disposal
Declaration of conformity: Hereby, Eurotronic Technology GmbH declares that the Air Quality Sensor Z-Wave Plus is in com- pliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://eurotronic.org/service/downloads/.
