Memory function:

or

Important notices

• The laser points to the location that will be measured.
No objects may get into the laser's line of measurement.
• The device compensates the measurement for different room
temperatures. Therefore allow the device a brief adaptation period
when changing locations with large temperature differences.
• The device is only conditionally useable in outdoor areas and cannot
be used in strong sunlight.
• The measurement results of outdoor measurements may be influenced
or falsified by rain, fog and snow.
• In unfavourable conditions, e.g. with poorly reflecting surfaces, the
maximum deviation may be greater than 3 mm.
• Carpeting, upholstery or curtains will not reflect the laser optimally.
Measure to flat surfaces.
• Measurements made through glass (window panes) can falsify
measurement results.
• An energy-saving function switches the device off automatically.
• Clean with a soft cloth. Water may not be allowed to penetrate the
housing.

Technical Data

Inside measurement range
Precision (typical)*
Laser class
Laser wavelength
Power supply
Dimensions (W x H x D)
Weight (incl. batteries)
Automatic switch-off
Operating temperature
Storage temperature
* measuring distance up to 10 m with strongly reflective target surface and at room temperature.
The measurement deviation may increase by ± 0.2 mm/m for greater distances and under
unfavourable measuring conditions such as strong sunlight or weakly reflective target surfaces.
14
GB
3 sec
View stored values
(Subject to technical changes without notice)
0.1 m - 40 m
± 2 mm / 10 m
2 < 1 mW
650 nm
2 x AAA 1.5 Volt batteries
43 x 110 x 27 mm
100 g
30
-10°C – 40°C
-20°C – 70°C
sec laser min device
