When installing:
Ensure that the connector is attached firmly.
1110 Speaker assembly
For access, remove these FRUs:
• "1010 Bottom door" on page 67
• "1040 Keyboard" on page 68
• "1080 Keyboard bezel assembly" on page 72
Removal steps of the speaker assembly
Step
Screw (quantity)
3
M2 × 3 mm, flat-head, nylon-coated (2)
1120 Smart card reader and smart card reader cable
For access, remove these FRUs:
Color
Torque
Black
0.181 Nm
(1.85 kgf-cm)
.
Chapter 9
Removing or replacing a FRU
75
