- Page 1 SMARTair ™ TS1000 Portable Programmer www.assaabloy.co.nz...
- Page 2 Introduction The SmartAir Access Control system is based mainly on products either running autonomously, running without connection to a Management computer, or Wireless Online where they do communicate continuously with the SmartAir Management software server. In the SmartAir range of Escutcheons, Cylinders and E-Motion Cabinet Locks, the control units operate purely on batteries, negating the need for wiring to access control points.
- Page 3 Connection & Clear Button 1 - RS232 connection to PC 2 - Jack lead connection for Escutcheons & Readers 3 - CLR (Clear) Button 4 - 3.5mm Socket for external 9VDC Power Supply 5 - Slot for Software License Key 1 - RS232 Connection to Computer The Portable Programmer is connected to the computer by means of a RS-232 cable with two connectors of 9 PINS.
- Page 4 Storage Capacity The Portable Programmer has a memory of 0.5MB. The portable programmer receives information about the doors forming part of a locking plan. This includes users who will have access to them, the Timezones in which they will have access, the Calendar of “Public Holidays” etc. Therefore the number of doors that we can transfer to the Portable Programmer will depend above all on the number of users forming part of the installation.
- Page 5 When clicking on the ‘Send Data to PP’ button, the software creates a data file which is sent to the Portable Programmer. The transmission time will depend on the amount of information we are sending. Once this task is complete, the window will display a message indicating that the information has been transmitted correctly. Once the data of the Locking Plan has been transmitted to the Portable Programmer we can transfer that information to the Escutcheons and Readers, as explained further in this manual.
- Page 6 By means of the F1, F2, F3, F4 and F5 function keys, we can access the different menus of the Portable Programmer. The Function Menu Keys are; Portable Programmer Doors Users Register of Openings Installation F1 Key explained By pressing the F1 key we access the menu of the Portable Programmer. •...
- Page 7 Date & Time After selecting the option ‘Date and Time’, press “OK” to access that function. The date and the time of the clock in the portable programmer is displayed. It cannot be modified because the programmer takes the computer’s date and time.
- Page 8 F2 Key explained – DOORS MENU By pressing F2 on the main screen of the Portable Programmer we access the Doors menu. This menu includes the ensuing operations: • Update • Initialise • Open • Test • Manufacturing To carry out the functions Update, Initialise and Open successfully, the Authorisation Key of the installation License must be inserted in the Portable Programmer.
- Page 9 Initialise Initialising an Escutcheon or Reader requires that Escutcheon or Reader to be configured in the ‘Doors’ Menu of the TS1000 Software, Users assigned and a Locking Plan created. This information can then be sent to the Portable Programmer and then downloaded from the PP into the specific item in the field.
- Page 10 Test The Test function of the Portable Programmer displays the Type of device and Version In the ‘Doors’ menu of the PP, select ‘Test’ using the Up and Down cursor keys. With Test selected, press “OK” and the test will start. Pressing “OK”...
- Page 11 See Openings The “See Openings” option allows the Portable Programmer to display all openings uploaded from Escutcheons and Readers, without connecting to the TS1000 Management Software computer. Using the Up or Down cursor keys select the option “See Openings” and press the “OK” key. The display will show a list of all the doors events have been uploaded from.
- Page 12 Select the required installation by using the Up or Down cursor keys and pressing the “OK” key. A confirmation message will be displayed. Configure Site The “Configure Site” option allows the Portable Programmer user to choose whether they want to see all the doors on the Initialise option of the Doors menu of the portable programmer or only the ones that have not been initialised.
- Page 13 Keyboard Test Clicking the tick key starts the keyboard test. The Portable Programmer will ask the user to press all the keys of the keyboard one by one, to check that they work properly. Pressing F1 will advance to the next screen asking for F2 to be pressed.
- Page 14 Clicking the cross button will cancel the operation and finish the test of the Portable Programmer. Clicking the tick key, the Portable Programmer will delete all stored data and it will start the Memory Test. Pressing “OK” will complete the test of the Portable Programmer. If the Portable Programmer has not detected any faults, the following message will be displayed.
