Summary of Contents for RTX Jack
- Page 1 ���������������������������� User Manual WPJ user manual_EU.indd 27/03/06 13:12...
- Page 2 Jack and/or an additional Extension units. We hope you will enjoy it. The Wireless Phone Jack is a wireless and cable free extension of the phone socket or VoIP adapter for an ordinary phone, modem, fax or satellite/cable set top box with integrated modem.
-
Page 3: Table Of Contents
IN THIS GUIDE Unpacking......... Base unit installation . -
Page 4: Unpacking
UNPACKING Carefully remove units from packaging. If there is any visible damage DO NOT attempt to operate the Wireless Phone Jack. Contact your dealer or shipping carrier immediately. BOX CONTENTS: Phone socket Phone line Indicator light One Base unit Indicator light... -
Page 5: Base Unit Installation
BASE UNIT INSTALLATION Connect the enclosed phone line cord to the Base unit and connect the other end to the phone wall socket.* If you have a phone connected to the wall socket, unplug it and connect it to the Base unit instead (remove plug adapter before connecting to the Base unit). -
Page 6: Extension Unit Installation
EXTENSION UNIT INSTALLATION The Extension unit can be connected to either a normal phone, modem, fax or satellite/cable set top box. Plug the phone line cord from your phone, modem, fax or satellite/cable set top box into the Extension unit. Phone, modem, fax or satellite/cable set top box Power supply plug... - Page 7 The light on top of the Extension unit will after a short period glow green (if switch is on C) or yellow (if switch is on S). The Extension unit is now installed and your Wireless Phone Jack are now ready for use. Computer Speech (Modem, fax, satellite/cable...
-
Page 8: Installation Of Extra Extension Units
INSTALLATION OF EXTRA EXTENSION UNITS Make sure the existing Wireless Phone Jack system (base and extension unit) is powered on. Unplug any cords attached to the Base unit (these will be connected again later). Plug the extra Extension unit into a power outlet near the Base unit and switch power on. -
Page 9: Operating Modes
OPERATING MODES BASE UNIT Light shows This means Suggested fix Steady Green Base unit is ready None No Extension units in use Normal operation Flashing Green One or more Extension None units is in use Normal operation No Light No power to Check that the Base unit Base unit is properly connected to... - Page 10 Light shows This means Suggested fix See Installation of Fast flashing Extension unit is extra Extension units Green de-registered No Light No power to Extension Check that the unit Extension unit is properly connected to a power outlet and the power is on Steady Red Extension unit is ready...
-
Page 11: Troubleshooting
TROUBLESHOOTING Problem Possible cause Solution No dialling tone – Base unit power not on – Check all power and available – Cables not correctly cable connections. If connected in doubt please refer to – Extension unit may the user manual. not be registered to Check that the base... - Page 12 Problem Possible cause Solution Phone connected This is normal. One to Extension unit ring delay is necessary rings one ring to allow transfer of later than phone Caller ID information connected to from base to Extension Base unit unit Warning: –...
