1. Mount on Solid Brick and Concrete Block
• Installers must verify that the supporting surface will safely support the combined load of the
equipment and all attached hardware and components.
User manual
W-B
WARNING
___ 5 ___
60mm 60mm
(2.4") (2.4")
ø 8mm
(ø 5/16")
1
Mark the
exact location of
mounting holes
2
Drill pilot holes
X
√
W-A
W-C
X
