Component checklist
IMPORTANT: Ensure you have received all parts against the component checklist prior to installing.
If any parts are missing or faulty, telephone the special franchiser for a placement.
wall plate
A
supporting spacer (x1)
C
Package M
M5x14 (x4)
M-A
M8x30 (x4)
M-E
Package W
ST5.5x50 (x2)
W-A
(x2)
M6x14 (x4)
M-B
washer(x4)
D5
M-
F
User manual
adapter bracket (x1)
supporting spacer (x1)
M8x20 (x4)
M-C
washer(x4) small spacer
D8
M-
G
concrete anchor (x2)
W-B
___ 4 ___
B
D
M6x30 (x4)
M-D
(x8) big spacer
M-H M-I
D6 washer (x2)
W-C
(x4)
