FROM
SUCTION
TO JETS
PUMP
REINFORCED
PUMP
PLATFORM
SUCTION FITTING: Feeds water to the pump. The suction
JETS:
fitting should be kept clean and free of debris. DO NOT
Where the water enters the bath. The jet direction can be controlled by rotating the nozzle.
RUN THE PUMP IF THE SUCTION COVER IS NOT IN
Water pressure can be regulated by turning the escheon (ring/bezzle around the jet) clockwise to reduce
PLACE.
the water pressure and counter clockwise to increase the water pressure.
PUMP: No maintenance is required on the tub pump. Do
The heater is set from the factory to maintain a maximum of 104 degrees (F).
not allow the pump to be run without water in the tub.
When bathing is completed, be sure pump is turned off.
AIR INDUCTION:
vigorous, bubbling stream of water from the jets. The system automatically introduces air into the system
IN LINE HEATER (OPTIONAL): Designed to maintain the
while the pump is operating.
bath's original water temperature. The heater is controlled
by an internal pressure switch that detects the movement of
SUCTION FITTING:
water through the system activating the heater. Accordingly,
debris. DO NOT RUN THE PUMP IF THE SUCTION COVER IS NOT IN PLACE.
the heater will not turn on unless the pump is running.
PUMP:
No maintenance is required on the tub pump. Do not allow the pump to be run without water
The heater's thermostat has a maximum setting of 104
in the tub. When bathing is completed, be sure pump is turned off.
degrees (F).
IN LINE HEATER (OPTIONAL):
This heater is equipped with a High-limit switch. Should the
The heater is controlled by an internal pressure switch that detects the movement of water through
water temperature exceed safe standards, the High-Limit
the system activating the heater. accordingly, the heater will not turn on unless the pump is running.
switch will shut off the heater. If tripped, push in the button
to reset. If the High-Limit trips again, contact a qualified
The heater's thermostat has a maximum setting of 104 degrees (F).
service technician.
This heater is equipped with a High-limit switch. Should the water temperature exceed safe standards,
CAUTION: The maximum temperature of the tub water
the High-Limit switch will shut off the heater. If tripped, push in the button to reset.
should not exceed 104 F (40 C). Temperatures of 100 F (38
If the High-Limit trips again, contact a qualified service technician.
C) to 104 F are considered safe for a healthy adult. Lower
CAUTION:
water temperatures are recommended for extended use
The maximum temperature of the tub water should not exceed 104 F (40 C).
and young children. Prolonged exposures to hot water
Temperatures of 100 F (38 C) to 104 F are considered safe for a healthy adult. Lower water
temperatures are recommended for extended use and young children. Prolonged exposures to hot
water may induce hyperthermia. Hyperthermia occurs when the internal temperature of the body
reaches a level several degrees above normal body temperature (98.6 F). Consult your physician
TUB
REINFORCED
BASE
TYPICAL TUB INSTALLATION
Allows the introduction of air into the water system. The mixing of air creates a more
Feeds water to the pump. The suction fitting should be kept clean and free of
Designed to maintain the bath's original water temperature.
Hydro-massage Bathtub - UL 1795
ON/OFF CONTROL (BUTTON -or- AMER-TOUCH PAD
JETS
SUCTION
TUB
LEGS
DRAIN
TO WASTE
may induce hyperthermia. Hyperthermia occurs when the
internal temperature of the body reaches a level several
degrees above normal body temperature (98.6 F). Consult
your physician for guidelines.
2013, The Praxis Companies, LLC
©
435 Industrial Rd., Savannah, TN 38372
Customer Service: 800.443.7269
www.praxiscompanies.com
AWP 3260 CWH
Installation Instructions
OVERFLOW
FLOOR
