parallel to bottom of skirt.
2) Mount (3) lower braces to floor approximately 1/4" behind line (1 center of skirt - 1 on each
end of the toe kick.)
3) Lift skirt until seam between tub and skirt is minimal, screw (5) into place.
4) Place decorative caps over screw heads.
NOTE: Caulking may be used to completely conceal seam between tub and skirt.
In some cases it may be necessary to widen the recess in the top brackets, if so,
use a hand saw and cut in 1/8" increments. DO NOT deepen recess.
Use precaution while entering or exiting the bath to prevent
accidental slips or falls.
Periodically check Ground Fault Circuit Interrupter to insure
it is operating correctly.
Keep electrical appliances at least (5) feet away from bath
while bathing.
Do not use oil based additives in the whirlpool bath.
OPERATION: Fill the bath high enough to cover the highest
wall jet allowing for body displacement of the water so as
not to over flow the bath but covering the highest jet. Turn
the pump motor on by one of two controls. The pump will
run until the button is pressed again.
1 Airswitch - A push button located on the bath. to turn on
bath, depress the button. The pump will run until the button
is depressed again.
2 Ameri-Touch low water cutoff. A sensor pad located on
the bath's deck. To turn on the bath, fill the tub high enough
to cover the highest wall jet allowing for body displacement
of the water so as not to overflow the bath but covering
the highest jet. Touch the sensor pad and the pump will
turn on. The built in timer will allow the bath to run for
20 minutes, then shut off automatically. If additional time is
desired, touch the sensor pad again. If you wish to shut off
the pump before time has expired, touch the sensor pad
and the pump will shut off.
For units equipped with Back jets, Neck Jets, Foot Jets, or air
Jets, the bath's pump must be turned on prior to activating
these features.
UPPER BRACKETS
RECESSED TOE KICK
LOWER BRACES
FRONT VIEW
AWP 3260 CWH
Installation Instructions
Hydro-massage Bathtub - UL 1795
DECORATIVE SCREW CAP
MOUNTING
TOP BRACKET RECESS
SCREW
LOWER BRACE

BACK VIEW

6

CARE AND MAINTENANCE

To clean the acrylic surface, use a damp cloth or sponge
with household soap or liquid detergent.
Do not use abrasive cleaners or solvents.
A paste wax or automobile rubbing compound may be
used to remove light surface scratches.
THE WHIRLPOOL SYSTEM SHOULD BE FLUSHED
PERIODICALLY (NOT TO EXCEED 90 DAYS).
To clean the whirlpool piping system, fill the tub with
water 2 inches above the highest jet and add 1/2 oz. liquid
dishwasher liquid per gallon of water. Run the system for 10
minutes then drain the bath.
SERVICE AND REPAIRS SHOULD BE PERFORMED BY A
QUALIFIED SERVICE TECHNICIAN.
TYPICAL TUB INSTALLATION
JETS: Where the water enters the bath. The jet direction can
be controlled by rotating the nozzle. Water pressure can be
regulated by turning the escheon (ring/bezzle around the
jet) clockwise to reduce the water pressure and counter
clockwise to increase the water pressure.
The heater is set from the factory to maintain a maximum
of 104 degrees (F).
AIR INDUCTION: Allows the introduction of air into the
water system. The mixing of air creates a more vigorous,
bubbling stream of water from the jets. The system
automatically introduces air into the system while the pump
is operating.
