- Page 1 M- 660.1- GL91- ENG Do cu men to: 11/1997 Edi zio ne: Rev.: GL91AMP Fla me detector In stal la tio n and ope ra ting manual NO TI FIER ITA LIA...
- Page 2 8. WIRE CONNECTION WITH CONVENTIONAL CONTROL PANELS ............. 4 9. WIRE CONNECTION WITH ANALOGUE PANELS ................5 10. WIRE CONNECTION FOR MORE DETECTORS WITH CONVENTIONAL CONTROL PANELS ..5 Doc. M-660.1-GL91-ENG Installation and operating manual NOTIFIER ITALIA GL91AMP.doc Rev. A.1 Page 1...
- Page 3 • an alarm circuit. 3. FUNCTIONING The GL91AMP detector is provided by a sensitive valve that at the presence of UV wave-lenght in the range 185- 260 nm. hoods and allawds the passage of current. The functioning is managed by a programmable micro-processor.
- Page 4 • Alarm delay: programmable 1-14 sec. • Spectral reponse: 185-260 nm. • Functioning temperature: - 20° + 60° C. • Protection degree: IP 55. • Relative humidity: minor/equal 95%. 5. INSTRUCTIONS Doc. M-660.1-GL91-ENG Installation and operating manual NOTIFIER ITALIA GL91AMP.doc Rev. A.1 Page 3...
- Page 5 • M6 = negative output line (balanced line). • M7 = common alarm relay. • M8 = N.O. or N.C. alarm relay. 8. WIRE CONNECTION WITH CONVENTIONAL CONTROL PANELS NOTIFIER ITALIA Installation and operating manual Doc. M-660.1- GL91-ENG Page 4 Rev.
- Page 6 9. WIRE CONNECTION WITH ANALOGUE PANELS 10. WIRE CONNECTION FOR MORE DETECTORS WITH CONVENTIONAL CONTROL PANELS Doc. M-660.1-GL91-ENG Installation and operating manual NOTIFIER ITALIA GL91AMP.doc Rev. A.1 Page 5...
- Page 7 NOTIFIER ITALIA Installation and operating manual Doc. M-660.1- GL91-ENG Page 6 Rev. A.1 GL91AMP.doc...
- Page 8 De li ve ry ti mes de pend on pro duct avai la bi li ty. All rights re ser ved. NO TI FIER ITA LIA S.r.l. NO TI FIER ITA LIA S.r.l. Via Grandi, 22 - 20097 San Do na to Mi la ne se (MI) Phone: 02/51897.1 (ISDN) Fax: 02/5189730 E- mail: no ti fier@notifier.it...
