Summary of Contents for Clarke PC108
- Page 1 HEATING TORCH SETS MODEL NO: SEE PAGE 2 PART NO: SEE PAGE 2 OPERATION & SAFETY INSTRUCTIONS ORIGINAL INSTRUCTIONS GC0620 -rev 6...
-
Page 2: Safety Precautions
INTRODUCTION Thank you for purchasing this CLARKE Heating Torch Set, designed for trade use. The torches are only to be used with propane gas and are supplied with a standard 3/8”BSP (LH) hose. THIS INSTRUCTION MANUAL INCLUDES THE FOLLOWING MODELS:... - Page 3 ASSEMBLY NOTE: A bottle of propane gas is required for use with this equipment, capable of delivering a pressure of 4 bar. (A regulator is provided) The bottle used must be of sufficient size to meet the needs of the torch and appropriate sizes are listed on page 5.
-
Page 4: Operation
OPERATION With the hose and regulator attached, and ensuring the gas tap on the torch is closed, i.e. turned fully clockwise, open the gas regulator valve. Gas will now be available at the torch, the volume of which will depend upon the regulator valve opening. -
Page 5: Gas Consumption
To remove the filter from the nozzle for cleaning, grasp the nozzle with a pair of mole grips or very carefully secure in a vice, then unscrew the filter. The parts on the following pages are all available from your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 6: Component Parts
COMPONENT PARTS PLK 1074 PC 108 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 7 PC109 PCSF109 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 8 PC216 PKP411 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
- Page 9 PS555 PS560 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 10: Component Parts List
COMPONENT PARTS LIST No Description Part No No Description Part No Handle assembly IDFC10901 21 Pipe burner IDFCSF10921 Handle/trigger assy 22 Flat burner IDFK41102 IDFCSF10922 Control knob assy IDFC10903 23 Soldering iron IDFK10123 adaptor Extension 80mm IDFC10904 24 Soldering iron IDFK10124 Extension 110mm IDFC10805... -
Page 11: Environmental Recycling Policy
ACCESSORIES A full range of accessories is available from your Clarke dealer. GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase.
