- Page 1 MICRO TORCH Model No. CBT1 1008 OPERATING & MAINTENANCE INSTRUCTIONS...
-
Page 2: Specifications
INTRODUCTION The CLARKE weld micro torch does not contain any butane gas when first purchased. Follow the gas filling instructions on page 7 to make it operative. GUARANTEE This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. - Page 3 APPLICATIONS • Welding • Brazing • Wire soldering • Silver soldering for computer boards, radio- controlled toys, or model railroads. • Jewellery • Optical glass frame work • Professional repair • Toy repairs • Plumbing • Home workshop • Tile laying •...
- Page 4 PART IDENTIFICATION Adjustment Lever Safety Lock Air Control Sleeve Valve Body Flame Guard Ignition Button Ignition Removable Base Gas Tank Gas Refill Opening SAFETY WARNINGS Do not touch flame guard when hot Keep out of reach of children. Butane gas is extremely flammable, please handle with care. Do not drop, puncture, incinerate, or expose to direct sunlight or temperatures above 50°c or 122°f.
- Page 5 OPERATION IGNITION Rotate the air control sleeve to line up the two holes. Slide the safety button upwards. Slide the adjustment lever slowly towards the left (+) position. Press the ignition button. The flame will light instantly. A good performance will not be achieved when: •...
- Page 6 ADJUSTMENTS FLAME LENGTH ADJUSTMENT The flame length can be adjusted from 12 mm to 32 mm. Slide the adjustment lever to the left (+) to make the flame longer, and to the right (-) to make the flame shorter and finally to shut it off.
- Page 7 MAINTENANCE REFILLING Use only high quality butane gas. Make sure torch is extinguished before refilling. Shake the gas canister a few times before use. Hold the torch upside down and insert the gas canister can nozzle vertically into the gas refill opening. •...
