2 TECHNICAL SPECIFICATIONS

- Maximum load on a workpiece carrier: 4 kg
- Maximum accumulated load on the transfer system: 35 kg for a maximum 3-meters unit.
- Electrical power supply of the motors: 380V three-phase
- Motor power:
(V = belt speed)
Air pressure supply = 5 to 6 bars
Every cylinder must be equipped with a flow limiter.
- Sound emission < 70 dB
- Weight of each part: See our catalogue Modular Transfer System & Flat belt conveyors.
http://elcom-automation.com/transfers/documentation
Warning: All load exceedance can lead to a premature wear of the belt or any other
parts.
I02-115 User manual & maintenance guide
of TLM 1500
V12m/mn = 0.09 Kw
V16m/mn = 0.09 Kw
Version 03
(translation of the original manual)
Page 3 sur 22
