SOUNDCRAFT
16
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM 16 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SoundCraft SM 16

Summary of Contents for SoundCraft SM 16

  • Page 1 SOUNDCRAFT USER GUIDE...
  • Page 2 Information in this manual is subject to change without notice and does not represent a commitment on the part of the vendor. Soundcraft Electronics Ltd. shall not be liable for any loss or damage whatsoever arising from the use of information or any error contained in this manual.

  • Page 3: Table Of Contents

    Introduction Introduction Precautions and Safety Instructions General Precautions Handling and Transport Power Supplies and Cables Signal Levels Installation Installation Wiring Considerations Power Supply (CPS900) Connections Wiring Conventions Module Block Diagrams Input Module Module Description, Operation and Specification 16 Jumper Options (RH PCB) Group Output Module Module Description, Operation and Specification 24 Master Module...
  • Page 4 Appendices Specification Notes Performance Specifications Dimensions Warranty Glossary...

  • Page 5: Introduction

    Introduction Introduction...

  • Page 6: Introduction

    The SM16 is a 16 bus dedicated monitor console to complement the Vienna and Europa FOH desks. The key features of the SM16 are: • 16 mono sends • stereo send • individual ON and PRE/POST fade switching on all sends •...
  • Page 7 Metering Each input module has its own bargraph meter in the overbridge. The groups are metered by bargraphs which are next to the faders on the output modules. The stereo mix/solo metering is by two illuminated VU meters, with integral peak LEDs, in the overbridge above the master module.

  • Page 8: Precautions And Safety Instructions

    General Precautions Avoid storing or using the mixing console in conditions of excessive heat or cold, or in positions where it is likely to be subject to vibration, dust or moisture. Do not use any liquids to clean the fascia of the unit: a soft dry brush is ideal. Use only water or ethyl alcohol to clean the trim and scribble strips.

  • Page 9: Signal Levels

    Signal Levels It is important to supply the correct input levels to the console, otherwise signalto noise ratio or distortion performance may be degraded; and in extreme cases, damage to the internal circuitry may result. Likewise, on all balanced inputs avoid sources with large commonmode DC, AC or RF voltages, as these will reduce the available signal range on the inputs.
  • Page 10 Introduction...

  • Page 11: Installation

    Installation Installation...

  • Page 12: Installation

    The SM16 is designed for reliability and high performance, and is built to the highest standards. Whilst great care has been taken to ensure that installations are made as troublefree as possible, care taken at this stage, followed by correct setting up will be rewarded by a long life and reliable operation.

  • Page 13: Connections

    ⁄ Wiring conventions The SM16 uses two different types of audio connector: 3-pin XLR and " 3-pole jacks. The latter are used in several configurations, as shown below. MICROPHONE INPUTS MIX L, R & WEDGE OUTPUTS AFL & PFL OUTPUTS TALKBACK INPUTS GROUP &...
  • Page 14 Installation...

  • Page 15: Module Block Diagrams

    Module Block Diagrams Module Block Diagrams...
  • Page 16 Input Module Module Block Diagrams...
  • Page 17 Group Output Module Module Block Diagrams...
  • Page 18 Master Module Module Block Diagrams...

  • Page 19: Input Module

    Input Module Input Module...

  • Page 20: Module Description, Operation And Specification

    Input The sensitivity of both the XLR and the HIGH IMPEDANCE (HI-Z jack) inputs is adjusted by the SENS control. Both inputs are electronically balanced. XLR input sensitivity: -2dBu to -70dBu, +10dBu to -20dBu (switched range.) High Impedance input sensitivity: +10dBu to -20dBu When the RNGE (Range) switch is depressed the lower sensitivity range of the input is selected to allow line level signals to be used.
  • Page 21 The HMF’s Q is 1.3, and is increased to 2.6 by depressing the HI-Q button. The peaking LMF (Low Mid) section has a maximum cut or boost of 15dB and the frequency is variable between 150Hz and 3kHz. The LMF’s Q is 1.3, and is increased to 2.6 by depressing the HI-Q button. The shelving LF section has a maximum cut or boost of 15dB and the frequency is variable between 20Hz and 400Hz.
  • Page 22 Insert Point The module insert point uses a groundcompensated send and an electronically balanced return, at a nominal level of -2dBu. The signal is accessible via separate 1/4" jacks on the rear connector panel. The insert point may be set to pre- or post-EQ by pushon jumpers. The factory default is post-EQ.

  • Page 23: Jumper Options (Rh Pcb)

    Stereo Mix The post-fader signal is sent to the stereo mix bus via the L/R (level) and PAN controls. The PAN control gives a 4.5dB centre drop. The mix bus send is activated by the ON switch, which has an integral green LED, and may be set pre- or post-fade by the PRE switch.
  • Page 24 Input and Output Levels XLR INPUT (electronically balanced) Sensitivity -2dBu to -70dBu, +10dBu to 20dBu Maximum Input Level +28dBu Input Impedance 2KΩ HI-Z INPUT (electronically balanced) Sensitivity +10dBu to -20dBu Maximum i/p level +30dBu Input Impedance >10KΩ balanced INSERT SEND (ground compensated) Nominal Level -2dBu Maximum Output Level...
  • Page 25 Rear Connectors INPUT (3 pin female XLR) Pin 1 Ground Pin 2 Signal (Hot) Pin 3 Signal (Cold) HI-Z INPUT, INSERT RETURN (1/4" 3-pole Jack) Signal (Hot) Ring Signal (Cold) Sleeve Ground DIRECT OUTPUT, INSERT SEND, (1/4" 3-pole Jack) Signal Ring Ground Sense Sleeve...
  • Page 26 Input Module...

  • Page 27: Group Output Module

    Group Output Module Group Output Module...

  • Page 28: Module Description, Operation And Specification

    Eight output modules are fitted in each console. The output module contains two group output sections, stacked one above the other. The lower sections control groups 1 - 8, while the upper sections control groups 9 - 16. The two sections have identical facilities.
  • Page 29 Talkback The momentary TB switch feeds the signal from the TALKBACK MICROPHONE to the group output; it is independent of the Fader position and the CUT switch. The group output is dimmed by 6db, and the engineer’s wedge speaker is dimmed by 20dB while the TB switch is active. Talkback may also be routed to all the group buses simultaneously by the INT talkback function on the master module;...
  • Page 30 Jumper Options Function Options Default Lower group bus programming J1 - J8 Group 1 - 8 According to Module Position Upper group bus programming J9 - J16 Group 9 - 16 According to Module Position Lower Meter Response Peak or Average Peak Upper Meter Response Peak or Average...
  • Page 31 Rear Connectors External Inputs (3-pin female XLR) Pin 1 Ground Pin 2 Signal (Hot) Pin 3 Signal (Cold) Insert Return (1/4" 3pole Jack) Signal (Hot) Ring Signal (Cold) Sleeve Ground Insert Send, (1/4" 3pole Jack) Signal (Hot) Ring Signal (Cold) Sleeve Ground PUSH...
  • Page 32 Group Output Module...

  • Page 33: Master Module

    Master Module Master Module...

  • Page 34: Module Description, Operation And Specification

    RS5512 LAMP OSCILLATOR The master module contains the stereo mix or sidefill output, the operator’s LEVEL headphones and wedge speaker outputs, a noise or sine wave test oscillator, the solo mode controls and master solo clear function, and internal/external talkback FREQ functions.
  • Page 35 Output Phase The PHASE switch, which has an integral red LED, reverses the phase of both left and right outputs. The outputs themselves are electronically balanced at +4dBu, on male XLRs on the rearcon. External Input A stereo external input, from XLRs on the lower rearcon, may be added to the mix buses.
  • Page 36 RS5512 LAMP External Solo Signals OSCILLATOR The PFL, AFL Left and AFL Right external inputs, from XLRs on the lower rearcon, allow signals from another console to be added to the PFL and AFL buses. The LEVEL external PFL level is trimmed by the PFL TRIM pot. When no solos are active on the console, both PFL and AFL left and right external signals are monitored by the FREQ ’phones and wedge.
  • Page 37 -20dBu and -50dBu. The momentary action FOH button, which has an integral green LED, initiates talkback to the front of house console using a Soundcraft proprietary system. The talkback mic signal is switched to the FOH OUT XLR, with a +15v DC common-mode voltage to signal the FOH console (a Vienna, Europa or 8000) that talkback is occurring.

  • Page 38: Jumper Options

    Mute Masters The four, latching, Mute Master buttons M1 - 4, which each have an integral red LED, control the four mute buses. Any inputs assigned to a mute bus will be cut by the appropriate mute master. PSU Status Indicators The three PSU Status Indicator LEDs (red) show that the PSU rails +/-17v (both sets of rails), +24v and +48v are working.
  • Page 39 TALKBACK MICROPHONE INPUT (Electronically Balanced) sensitivity -20dBu to -50dBu maximum i/p level 0dBu input impedance 2kΩ PHONES OUTPUT (Unbalanced) nominal level +4dBu maximum output level +20dBu into 600Ω 0dBu into 8Ω output impedance 50Ω Rear Connectors External Inputs, External Talkback In, Talkback Mic In (3-pin female XLR) Pin 1 Ground...
  • Page 40 Rear Connector Panels (Note: Group Output Connectors have been removed from the diagram for clarity). PUSH PUSH PUSH PUSH PUSH PUSH PUSH Power Supply Connector Panel Master Module...
  • Page 41 Appendices Appendices...
  • Page 42 SPECIFICATION NOTES AND CONDITIONS A The Console has a nominal output level of +4dBu: all input sensitivities are relative to this, i.e., with line input gain set to ’0’, an input of 0dBu will give an output of +4dBu at any group or mix output, and a sensitivity of +4dBu gives unity gain from input to output.
  • Page 43 Measured on a 40 channel console. Frequency response Line input to any output: 20Hz - 20kHz, +0/-0.5dB Crosstalk (measured at 1kHz) Channel CUT isolation >100dB Channel Fader isolation >75dB Channel Send Pot isolation >90dB Channel Send ON isolation >100dB Group Fader isolation >100dB Group CUT isolation >110dB...
  • Page 44 SM16 Outline Dimensions All dimensions are in millimetres Dimensions - end view 120.6 Length : 48 channel - 2142.3 40 channel - 1859.1 32 channel - 1575.9 101.5 366.5 140.25 892.4 48 Channel Console 32 Channel Console 40 Channel Console Appendices...
  • Page 45 Equipment has been properly installed in accordance with instructions contained in Soundcraft’s manual; and b) the End User has notified Soundcraft or the Dealer within 14 days of the defect appearing; and c) no persons other than authorised representatives of Soundcraft or the Dealer have effected any replacement of parts maintenance adjustments or repairs to the Equipment;...
  • Page 46 Auxiliary Send an output from the console comprising a mix of signals from channels and groups derived independently of themain stereo group mixes. Typically the feeds to the mix are implemented on rotary level controls. Balance the relative levels of the left and right channels of a stereo signal. Clipping the onset of severe distortion in the signal path, usually caused by the peak signal voltage being limited by the circuit’s power supply voltage.
