2.

Initial Radio Configuration

Below is an outline of recommended settings for the MicroHard IPnDDL, to be set prior to
connecting to the Triad RF Systems BDA.
2.1

Radio Output Power

Please be sure to terminate the RF ports on the radio before powering on the radio.
It is recommended to initially set the radio output power to its minimum value. This will
prevent any potential damage to the Triad BDA. The ideal radio power will depend on
several factors such as: amplifier gain, data rate required, and amplifier output power.
Consult the Triad BDA specification sheet for linear power output.
2.2

Frequency

Set the radio operating frequency within the range of the Triad BDA frequency range.
Consult specification sheet for frequency details.
2.3

Data Link Distance

Set the data link distance to desired or expected operating distance.
Before powering on the radio, ensure that the RF ports are properly
terminated, or connected to their antennae. Operating the unit with the RF
ports open can cause damage to the radio.
