Overview - Triad RF Systems Microhard IPnDDL Integration Manual

1.

Overview

This document details the integration and setup of a MicroHard IPnDDL data link radio with a
compatible Triad RF Systems Bi-Directional Amplifier. This will include instructions for wiring
connections as well as initial and ideal radio settings to maximize data link performance.
The MicroHard IPnDDL radio is used in a variety of military and commercial applications. Some
of the applications in which these radios are used may present difficult RF or physical
environment conditions.
Certain custom-designed products may have been supplied with a different set of operating
manuals or interface control documents. In those cases, the recommendations of the
documents supplied supersede the ones contained in this manual.
The instructions provided here will require a copy of the Triad RF Systems BDA specification
sheet, which can be obtained from our website at www.triadrf.com. For additional assistance
please contact us at support@triadrf.com
Notes that accompany the warning symbol denote instructions and
guidelines that must be followed. Failure to follow these guidelines may
result in damage to the amplifier that is not covered by Triad's product
warranty.
