Shelti Blue Line Hockey Thunderdome Assembly Instructions

Thank you for purchasing a Shelti product. All of us at Shelti want you to be completely satisfied with
your Thunderdome Dome Hockey game, so feel free to contact us for help with the assembly of your
product, Shelti parts, or other information you may require.
Tools Required:
14mm Wrench or Socket (Included)
12mm Wrench or Socket (Included)
4mm Hex Wrench (Included)
Phillips Head Screw Driver
Level
Step #1 -
Remove Parts from Box
Remove the pedestal from its box. Locate and remove the leg levelers and bolt package.
Contents
Dome Hockey Cabinet
Split Pedestal
Accessory Package
Assembly Instructions
Accessory Package Contents
Leg Levelers
Cabinet Bolt - Hex Head M8x55mm (1 Extra)
Cabinet Washer - M8 (1 Extra)
Hex Wrench - 4 mm
Electronic Scoring Unit
Flat Head Screw - Phillips Head M5x12mm
9/16 Washer - M6 (Not needed)
Nut - M5
Rounded Head Screw - Phillips Head M3x14mm
Washer - M5
Dome Hockey Puck (1" Dia.)
Pedestal Bolt
Pedestal Washer
Pedestal Nut
Thunderdome Side Label
K4
© Copyright 2004, Shelti Inc., Bay City • Michigan
Assembly Instructions
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
Part Number
TD-DPA-0
TD-PDA-1
TD-ASA-0
210-0144-0
201-0074-0
301-0043-0
303-0025-0
205-0057-0
210-0145-0
301-0044-0
303-0026-0
302-0016-0
301-0045-0
303-0027-0
210-0131-0
301-0058-0
303-0030-0
302-0022-0
217-0002-0
Quantity
1
1
1
1
4
11
11
1
1
2
2
2
1
1
3
8
16
8
2
