Summary of Contents for ESCALADE American Legend Phazer HT600

  • Page 1 y t i . s t f l l 888-996-2729 gameroom . s t l l i dat e code date code (if c i l . t r HT600 2 - HT600 - - HL Dat e Code: Purchase Date: PLEASE RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE All Rights Reserved ©...

  • Page 2: Assembly Tips

    READ AND FOLLOW ALL ASSEMBLY, OPERATION, AND SAFETY INSTRUCTIONS CAREFULLY. AT LEAST TWO ADULTS ARE NEEDED TO PUT THIS HOCKEY TABLE TOGETHER. All Rights Reserved. © 2016 Escalade Sports For Customer Service Call 1-888-996-2729...
  • Page 3 NOTE: A3 Felt Pads may already be attached to Strikers. NOTE: Use for H5 Allen Head Bolts WARNING: CHOKING HAZARD Small parts. Not for children under 3 yrs. All Rights Reserved. © 2016 Escalade Sports For Customer Service Call 1-888-996-2729...
  • Page 4 ON/OFF Slot P16 = 2 pcs P15 = 4 pcs Leg Support Puck Catcher Board Hole Trim WARNING: CHOKING HAZARD Small parts. Not for children under 3 yrs. All Rights Reserved. © 2016 Escalade Sports For Customer Service Call 1-888-996-2729...

  • Page 5: On/Off Switch

    P24 = 2 pcs Junction Box Metal Bracket Upper Puck Catcher Lighting LED Rail (Factory Installed) (Factory Installed) WARNING: CHOKING HAZARD Small parts. Not for children under 3 yrs. All Rights Reserved. © 2016 Escalade Sports For Customer Service Call 1-888-996-2729...

  • Page 6: Parts Required

    PARTS REQUIRED: 20 pcs - H1 Allen Head Bolt 2 pcs - P8 End Apron 20 pcs - H2 Flat Washer 1 pc - P9 Side Apron 1 pc - P1 Air Hockey 1 pc - P10 Side Apron with ON/OFF Slot Table Cabinet 1 pc - T1 Allen Wrench STEP 1:...
  • Page 7 PARTS REQUIRED: 4 pcs - P13 Corner Post STEP 2: Slide the P13 Corner Posts down onto each end of End Apron and Side Apron as shown in FIGURE 2. IMPORTANT NOTE: SLIDE P13 CORNER POSTS WITH ARROW POINTING DOWN. USE T1 ALLEN WRENCH TO TIGHTEN ALL H1 BOLTS AT THIS TIME.
  • Page 8 PARTS REQUIRED: 22 pcs - H6 Phillips Round Head Screw 2 pcs - P16 Puck Catcher Hole Trim 2 pcs - P18 Lower Puck Catcher with Sensor Wires 2 pcs - P22 Upper Puck Catcher STEP 3: Install P13 Corner Posts using H6 Screws as shown in FIGURE 3. Install P16 Puck Catcher Hole Trims using pre-drilled holes with H6 Screws as shown in FIGURE 3.
  • Page 9 PARTS REQUIRED: 24 pcs - H1 Allen Head Bolt 4 pcs - P2 Left Leg Panel 4 pcs - P5 Back Leg Panel 24 pcs - H2 Flat Washer 4 pcs - P3 Right Leg Panel 1 pc - T1 Allen Wrench 24 pcs - H3 Phillips Flat 4 pcs - P4 Front Leg Panel Head Screw...
  • Page 10 PARTS REQUIRED: 32 pcs - H3 Phillips Round Head Screw 4 pcs - P14 Leg Leveler 4 pcs - P6 Leg Bottom Board 4 pcs - P15 Leg Support Board STEP 5: Install P15 Leg Support Boards onto each assembled Leg using H3 Phillips Round Head Screws as shown in FIGURE 5.
  • Page 11 PARTS REQUIRED: 16 pcs - H4 Flat Washer 2 pcs - P7 End Leg Panel 16 pcs - H6 Phillips Round Head Screw 1 pc - T2 Allen Wrench 16 pcs - H8 Allen Head Bolt STEP 6: Install each Leg assembly onto P1 Air Hockey Table Cabinet using four H8 Allen Head Bolts with four H4 Flat Washers as shown in FIGURE 6.
  • Page 12 PARTS REQUIRED: 6 pcs - H7 Phillips Round Head Screw 1 pc - P19 A/C Adaptor 1 pc - P20 ON/OFF Switch 1 pc - P21 Metal Bracket STEP 7: Install the P20 ON/OFF Switch onto inside of P10 Side Apron with ON/OFF Slot using pre-drilled holes with H7 Screws as shown in FIGURE 7.

  • Page 13: Important Note

    PARTS REQUIRED: 2 pcs - H5 Allen Head Bolt THIS STEP REQUIRES FOUR OR MORE ADULTS. 1 pc - P17 Scorer Console VERY CAREFULLY TURN THE TABLE OVER AND SET IT ON 1 pc - T3 Allen Wrench ITS LEGS. BE CAREFUL, THE TABLE IS HEAVY. STEP 8: With the help of at least three other adults, carefully lift and rotate table into upright position.
  • Page 14 Congratulations! You have now assembled your Hockey Table. Please note the Care and Use instructions below to ensure many years of trouble free use of your Hockey Table. CARE AND USE OF YOUR HOCKEY TABLE . 1 Use only a suitable 120v AC household outlet, and insure the cord is not a trip hazard. For long life and best play from your air hockey table, apply spray furniture polish to a clean cloth and wipe down the playfield with air motor running to make the pucks slide faster before first play and frequently thereafter.

  • Page 15: Product Parts List

    ELECTRICAL CONNECTIONS & SPARE PARTS DRAWINGS - Scoring Console - ON/OFF To Wall Switch Outlet - Junction Box - A/C Adapter - Lower Puck Catcher - Lower Puck with Sensor Wires Catcher with Sensor Wires - Lighting LED Rail PRODUCT PARTS LIST MODEL: HT600 Part# Description...
  • Page 16 ESCALADE P " . ) " l a i l l a v i t 888-996-2729 ® l l i l i a gameroom Other than shipping requirements, no charge will be made for such replacement of in-warranty products.
