- Page 1 Vallauris Outdoor Sofa Assembly Instructions iNClUDES iMPOrTANT SAFETy iNFOrMATiON. PlEASE rEAD AND KEEP FOr FUTUrE rEFErENCE.
- Page 2 Should you prefer to speak with a customer service representative, you may call toll free : 1-855-372-2315.
- Page 3 The exceptions or exclusions to this warranty are: Limited Warranty • Upholstery material and foam cushion material is warranted against defects in material and workmanship for a period of one year, beginning on the date of purchase as Millwork Holdings seating products are warranted against shown on the original sales receipt.
- Page 4 Guidelines Thank you for selecting an Elle Decor piece! FAILURE TO FOLLOW THESE WARNINGS WHEN IN USE COULD RESULT IN INJURY Our primary objective is to provide fast, friendly customer service to all of our customers. We are here to help if you have any questions, comments, or are in •...
- Page 5 WARNING: DO NOT lET CHilDrEN PlAy iN Or ArOUND THE UNiT DUE TO THE POSSiBlE riSK OF FiNgEr ENTrAPMENT. Pre-Assembly Preparation: Cleaning & Maintenance: Please read through this instruction before beginning • Wash frame parts with mild soap and water, rinse assembly of this item.
- Page 6 Parts Inventory Back panel Left panel Right panel Base panel Right panel foot Foot...
- Page 7 NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED. STEP 1 1. lift to insert left Side Panel’s (1) attached hardware into Base Panel’s (2) attached hardware. Push downwards until fully locked in place. 2. Attach foot (5) to Base Panel (2) by using M6x30mm bolt (A) with washer (B) and tighten using Allen Key (F).
- Page 8 NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED. STEP 2 1. lift to insert Back Panel (3) and attach hardware into left Side Panel’s (1) hardware and push down until fully connected. 2. insert M6 x 40mm bolt (C) with washer (B) through Base (2) connecting to Back Panel (3) by using Allen Key (F) and fully...
- Page 9 NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED. STEP 3 1. lift to insert right Side Panel (4) and locate right Side Panel’s (4) attached hardware into Base Panel (2) and Back Panel’s (3) attached hardware and push down until fully connected.
- Page 10 NOTE: DO NOT FULLY TIGHTEN BOLTS UNTIL ALL PARTS ARE ASSEMBLED. STEP 5 insert Cushions (g) and (i) STEP 4 into Cushion covers (H) and (J). Attach Plate (E) with M6 x 15mm bolt (D) and Washer (B) and fully tighten using Allen Key (F)
- Page 11 Thank you for your purchase! We hope you love your Elle Decor piece as much as we do.
