- Page 1 Ophelia Assembly Instructions INCLUDES IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
- Page 2 Should you prefer to speak with a customer service representative, you may call toll free: 1-855-372-2315.
-
Page 3: Limited Warranty
The exceptions or exclusions to this warranty are: Limited Warranty • Upholstery material and foam cushion material is warranted against defects in material and workmanship for a period of one year, beginning on the date of purchase as Millwork Holdings seating products are warranted against shown on the original sales receipt. - Page 4 Guidelines FAILURE TO FOLLOW THESE WARNINGS Thank you for selecting an Elle Decor piece! WHEN IN USE COULD RESULT IN INJURY Our primary objective is to provide fast, friendly customer service to all of our customers. We are here to help if you have any questions, comments, or are in •...
-
Page 5: Maintenance
WARNING: DO NOT LET CHILDREN PLAY IN OR AROUND THE UNIT DUE TO THE POSSIBLE RISK OF FINGER ENTRAPMENT. Pre-Assembly Preparation: Maintenance: • Inspect and tighten all bolts on a regular basis to Please read through this instruction before beginning ensure proper performance and safety. - Page 6 1 Step One: Inventory Parts Casters Star Base Gas Lift Seat Plate Quantity: 5 Quantity: 1 Quantity: 1 Quantity: 1 Seat Cushion Back Cushion 1” Screws 1-1/4” Screws Quantity: 1 Quantity: 1 Quantity: 4 Quantity: 4 Allen Key Quantity: 1...
- Page 7 2 Step Two： Place the Star Base (B) upside down and insert 5 Casters (A) into the holes on the Star Base (B). 3 Step Three： Turn the Star Base (B) over and insert the Gas Lift (C) through the center hole on top of Star Base (B).
- Page 8 4 Step Four： Attach Seat Plate (D) to the bottom of the Seat Cushion (E) (with the front of the seat plate facing the front of seat cushion). Attach by using 1” Screws (G) for the holes of the Seat Plate (D) with the Allen Key (I). *Note: Align the seat plate so the FRONT on the seat plate matches the FRONT label on the bottom of the seat cushion.
- Page 9 6 Step Six： Position the assembled chair upright with the Seat Plate (D) facing down. Insert the Gas Lift (C) into the center hole of the Seat Plate (D) and press down until fully engaged.
- Page 10 Operating Instructions To Adjust Seat Height To Adjust Tension on the Tilt While seated, lean forward and reach under the right side of Reach under the front center of the chair, grasp the round the chair to find the handle. Lift the handle and raise your knob (R) and turn it counter - clockwise to stiffen the tilt body up slightly to allow the chair to rise to the desired mechanism.
- Page 11 To Operate Tilt Lockout While seated, reach under the right side of the chair to find the height adjustment handle. Pull the handle all the way out (away from the seat plate) to allow the chair to tilt backwards. To lock the chair in the upright or vertical position, sit upright and push the handle in towards the seat plate.
