LG 37LH250H Service Manual

LG 37LH250H Service Manual

Chassis la96a
Hide thumbs Also See for 37LH250H:

Advertisement

Quick Links

LCD TV
SERVICE MANUAL
CHASSIS : LA96A
MODEL : 37LH250H
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/NO : MFL62195501 (0907-REV00)
North/Latin America
Europe/Africa
Asia/Oceania
37LH250H-UA
Internal Use Only
http://aic.lgservice.com
http://eic.lgservice.com
http://biz.lgservice.com
Printed in Korea

Advertisement

loading
Need help?

Need help?

Do you have a question about the 37LH250H and is the answer not in the manual?

Questions and answers

Related Manuals for LG 37LH250H

Summary of Contents for LG 37LH250H

  • Page 1 Internal Use Only North/Latin America http://aic.lgservice.com Europe/Africa http://eic.lgservice.com Asia/Oceania http://biz.lgservice.com LCD TV SERVICE MANUAL CHASSIS : LA96A MODEL : 37LH250H 37LH250H-UA CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. P/NO : MFL62195501 (0907-REV00) Printed in Korea...

  • Page 2: Table Of Contents

    SPECIFICATION ..................6 ADJUSTMENT INSTRUCTION .............. 10 TROUBLE SHOOTING ................17 BLOCK DIAGRAM.................. 23 EXPLODED VIEW .................. 25 SVC. SHEET ....................Copyright LG Electronics. Inc. All right reserved. - 2 - LGE Internal Use Only Only for training and service purposes...

  • Page 3: Product Safety

    An other abnormality exists that must be corrected before the receiver is returned to the customer. Copyright LG Electronics. Inc. All right reserved. - 3 - LGE Internal Use Only Only for training and service purposes...
  • Page 4 Alternatively, obtain and wear a commercially available discharging wrist strap device, which should be removed to prevent potential shock reasons prior to applying power to the Copyright LG Electronics. Inc. All right reserved. - 4 - LGE Internal Use Only Only for training and service purposes...
  • Page 5 CAUTION: Maintain original spacing between the replaced component and adjacent components and the circuit board to prevent excessive component temperatures. Copyright LG Electronics. Inc. All right reserved. - 5 - LGE Internal Use Only Only for training and service purposes...

  • Page 6: Specification

    2) Humidity : ~ 80 % Storage Environment 1) Temp : -20 ~ 60 deg 2) Humidity : ~ 85 % Copyright LG Electronics. Inc. All right reserved. - 6 - LGE Internal Use Only Only for training and service purposes...
  • Page 7 Typ. ** The W/B Tolerance is ±0.015 for Typ. -0.015 0.293 +0.015 Adjustment Warm Typ. 0.313 Typ. -0.015 0.329 +0.015 Copyright LG Electronics. Inc. All right reserved. - 7 - LGE Internal Use Only Only for training and service purposes...
  • Page 8 HDTV 1080P 1920*1080 26.97 23.976 74.176 HDTV 1080P 1920*1080 33.75 30.000 74.25 HDTV 1080P 1920*1080 33.71 29.97 74.176 HDTV 1080P Copyright LG Electronics. Inc. All right reserved. - 8 - LGE Internal Use Only Only for training and service purposes...
  • Page 9 0~2.5 REAR A/V DECO & MAX 3.0mm GAME CONT ROL (Measure) (DQA) 90~92.5 ANGEL +/-90(SPEC) STAND SWIVEL ANGEL (Measure) (DQA) Copyright LG Electronics. Inc. All right reserved. - 9 - LGE Internal Use Only Only for training and service purposes...

  • Page 10: Adjustment Instruction

    Because PTC Download JIG has internal memory, it can save download files using download program (SAP Configuration). Push the START button (4) after file saving, then it execute download. Copyright LG Electronics. Inc. All right reserved. - 10 - LGE Internal Use Only Only for training and service purposes...
  • Page 11 5. Click “Auto” tab and set as below 6. Click “Run”. 7. After downloading, check “OK” message. filexxx.bin (7) .OK Copyright LG Electronics. Inc. All right reserved. - 11 - LGE Internal Use Only Only for training and service purposes...
  • Page 12 • ad 00 00 [Enter ADC adj. mode] • ad 00 10 [Adjust 480i Comp1/1080p Comp1/1024*768 RGB] • ad 00 90 End adj. Copyright LG Electronics. Inc. All right reserved. - 12 - LGE Internal Use Only Only for training and service purposes...
  • Page 13 5.2 COMPONENT input ADC 5.2.1 Component Gain/Offset Adjustment • Convert to Component in Input-source. • Signal equipment displays. - Impress Resolution 480i Copyright LG Electronics. Inc. All right reserved. - 13 - LGE Internal Use Only Only for training and service purposes...
  • Page 14 - Impress Resolution 480i/1080p/RGB 5.4.4 EDID DATA •Reference: Download is only possible in POWER ON MODE. • HDMI I [C/S: 1DBA] Copyright LG Electronics. Inc. All right reserved. - 14 - LGE Internal Use Only Only for training and service purposes...
  • Page 15 •Color Analyzer Matrix should be calibrated using CS-1000 G Cut B Cut Warm R Gain G Gain B Gain R Cut G Cut Copyright LG Electronics. Inc. All right reserved. - 15 - LGE Internal Use Only Only for training and service purposes...
  • Page 16 (80°~ 100°) - In case of LCD, B/L on should be checked using no signal or Full white Pattern Copyright LG Electronics. Inc. All right reserved. - 16 - LGE Internal Use Only Only for training and service purposes...

  • Page 17: Troubleshooting

    Check Power board or Module P700 20pin : high Check Mstar LVDS output Replace Mstar(IC100) or Main board R812, R813,..., R821 Copyright LG Electronics. Inc. All right reserved. - 17 - LGE Internal Use Only Only for training and service purposes...
  • Page 18 IC1001 4pin Check IC1005(19",22") Check CVBS signal. Bad Tuner. TU1001 #19 Pin Check Mstar LVDS output Replace Mstar(IC100) or Main board. Copyright LG Electronics. Inc. All right reserved. - 18 - LGE Internal Use Only Only for training and service purposes...
  • Page 19 C113, C108, C114, R146, R149 If no problem, check signal line. Check Mstar LVDS output Replace Mstar(IC100) or Main board. Copyright LG Electronics. Inc. All right reserved. - 19 - LGE Internal Use Only Only for training and service purposes...
  • Page 20 Check HDMI Signal Replace Main board. If no problem, check signal line. Check Mstar LVDS output Replace Mstar(IC100) or Main board. Copyright LG Electronics. Inc. All right reserved. - 20 - LGE Internal Use Only Only for training and service purposes...
  • Page 21 Replace NTP(Audio AMP) IC500 Check Connector & P600 Replace connector if found to be damaged. Check speaker resistance Replace speaker. and connector damage. Copyright LG Electronics. Inc. All right reserved. - 21 - LGE Internal Use Only Only for training and service purposes...
  • Page 22 Check SIF buffer signal. Check SIF Signal line. Follow procedure All source audio Replace Mstar(IC100) trouble shooting guide. or Main board. Copyright LG Electronics. Inc. All right reserved. - 22 - LGE Internal Use Only Only for training and service purposes...

  • Page 23: Block Diagram

    BLOCK DIAGRAM Copyright LG Electronics. Inc. All right reserved. - 23 - LGE Internal Use Only Only for training and service purposes...
  • Page 24 Half-NIM Tuner Copyright LG Electronics. Inc. All right reserved. - 24 - LGE Internal Use Only Only for training and service purposes...

  • Page 25: Exploded View

    X-RADIATION, Shock, Fire, or other Hazards. Do not modify the original design without permission of manufacturer. Copyright Copyright LG Electronics. Inc. All right reserved. LG Electronics. Inc. All right reserved. - 25 - LGE Internal Use Only...
  • Page 26 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 37LH250H ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 27 JK501 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 28 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 37LH250H ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 29 C788 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 30 3216 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 31 TDDR_D[5] SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 32 MDS61887701 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 33 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 37LH250H ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 34 2SC3875S(ALY) SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 35 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 37LH250H ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR FPGA THE CRITICAL COMPONENTS IN THE...
  • Page 36 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 37LH250H ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 37 4.7K Q1201 BSS83 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. 37LH250H 09.05.19 FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR UART THE CRITICAL COMPONENTS IN THE...
  • Page 38 USB +5V Over Current Protection --> USB Jack SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. 37LH250H FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
  • Page 39 R2538 SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION. FILRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS 37LH250H 09.05.19 ESSENTIAL THAT ONLY MANUFATURES SPECFIED PARTS BE USED FOR THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
