Krom Schroder DL K Series Operating Instructions

035005
D GB F NL I
TR CZ PL RUS H
Operating instructions
Pressure switches for air DL..K
Cert-Version 09.13
Contents Contents
Pressure switches for air DL..K . . . . . . . . . . . 1
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Checking The Usage . . . . . . . . . . . . . . . . . . . . . 
Type Code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Designations . . . . . . . . . . . . . . . . . . . . . . . . 2
Type Label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . 4
Declaration Of Conformity . . . . . . . . . . . . . . . . 4
Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
E DK S N P GR
www.docuthek.com
Safety Safety
Please read and keep in a safe place
Please read through these instructions
carefully before installing or operating. Following the
installation, pass the instructions on to the opera-
tor. This unit must be installed and commissioned
in accordance with the regulations and standards
in force. These instructions can also be found at
www.docuthek.com.
Explanation of symbols
• , 1 ,  , 3 ... = Action
▷
= Instruction
Liability
We will not be held liable for damage resulting from
non-observance of the instructions and non-com-
pliant use.
Safety instructions
Information that is relevant for safety is indicated in
the instructions as follows:
DANGER
Indicates potentially fatal situations.
WARNING
Indicates possible danger to life and limb.
CAUTION
Indicates possible material damage.
All interventions may only be carried out by qualified
gas technicians. Electrical interventions may only be
carried out by qualified electricians.
Conversion, spare parts
All technical changes are prohibited. Only use OEM
spare parts.
Transport
On receipt of the product, check that the delivery is
complete (see Part designations). Report any trans-
port damage immediately.
Storage
Store the product in a dry place. Ambient tempera-
ture: see Technical data.
Changes to edition 10.1
The following chapters have been changed:
– New layout:
Installation
Wiring
Adjustment
Accessories
Technical data
Declaration of conformity
GB-1
