ECK24 Kegerator Installation Guide
1
3
4
11
6
10
8
1. Faucet Handle
2. Faucet
3. Beer Tower
4. Guard Rail
5. Drip Tray
6. Cylinder Strap
7. Metal Keg Floor Support
8. Casters (x4)
2
5
12
9
7
9. Bottle Reservoir and Tube
10.
Beer Line
11. Thermostat Control
12.
Internal Fan Pipe
13. Tower Gasket
14. Tower Bolts (4)
15. Rail Screws (4)
13
14
15
Tools Needed:
- Wrench
- Flat Head Screwdriver
- Phillips Head Screwdriver
For additional information
visit edgestar.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EdgeStar ECK24
Summary of Contents for EdgeStar ECK24
- Page 1 ECK24 Kegerator Installation Guide 1. Faucet Handle 9. Bottle Reservoir and Tube Tools Needed: - Wrench 2. Faucet Beer Line - Flat Head Screwdriver 3. Beer Tower 11. Thermostat Control - Phillips Head Screwdriver 4. Guard Rail Internal Fan Pipe 5.
- Page 2 Install Tower Secure Tower Mount the tower gasket Once the beer line (#10) (#13) by lining it up with is fed into the unit line up the preexisting holes at the holes at the bottom of the top of the unit. the tower, install the four Install the tower (#3) by bolts (#14) and secure...
- Page 3 Please refer to the owner’s manual for a full discourse on installation, usage and maintenance. If you have any questions about the installation of this appliance, feel free to contact EdgeStar service at 866.319.5473 or consult a qualified installer. Neither the manufacturer nor its distributors shall be liable for any incidental, consequential, indirect, special, or punitive damages of any nature, including without limitation, lost revenues or profits, or any other damage whether based in contract, tort, or otherwise.
