KC3000 Kegerator Installation Guide
12
1. Faucet Handle
2. Faucet
3. Beer Tower
4. Guard Rail
5. Drip Tray
6. Regulator
7. CO
Tube
2
Tools Needed:
- Wrench
- Flat Head Screwdriver
- Pair of Pliers/Clamp Crimper
1
2
3
5
6
13
7
8
9
11
8. CO2 Cylinder (supplied empty)
9. Cylinder Clip
10. American Sankey Keg Coupler
11. Metal Keg Floor Support
12. Casters (x4) and Washers (x2)
13. Beer Line
14. Half Barrel Keg (not included)
4
10
14
15
16
17
18
19
20
15. Neoprene Washer
16. Hose Clamps (2)
17. Tower Plug
18. Long Bolt and Nut
19. Tower Gasket
20. Screws (4)
For additional information
visit edgestar.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for EdgeStar KC3000
Summary of Contents for EdgeStar KC3000
- Page 1 KC3000 Kegerator Installation Guide 1. Faucet Handle 8. CO2 Cylinder (supplied empty) 15. Neoprene Washer 2. Faucet 9. Cylinder Clip 16. Hose Clamps (2) 3. Beer Tower 10. American Sankey Keg Coupler 17. Tower Plug 4. Guard Rail 11. Metal Keg Floor Support 18.
- Page 2 Install Caster Wheels Remove Plug Before assembly, make Carefully remove the sure to empty the inside tower plug (#17) of the unit including all located on the top of shelves and metal keg the unit by opening the floor (# 11). Carefully cabinet, and with your lay the unit on its back.
- Page 3 Connect Regulator to Cylinder Connect Tube to Regulator Attach the CO 2 regulator (#6) to Make sure the shut off CO 2 cylinder (#8) by valve at the bottom of the screwing the regulator nut onto regulator is closed (9 the cylinder valve and tightening o’clock position).
- Page 4 Please refer to the owner’s manual for a full discourse on installation, usage and maintenance. If you have any questions about the installation of this appliance, feel free to contact EdgeStar service at 866.319.5473 or consult a qualified installer. Neither the manufacturer nor its distributors shall be liable for any incidental, consequential, indirect, special, or punitive damages of any nature, including without limitation, lost revenues or profits, or any other damage whether based in contract, tort, or otherwise.
