- Page 1 Gispen IC 单独工作区 Installation manual 安装指南 单独 Tools 工具 Nr. 5 M8x10 M8x12 M6x10 or (16x) (4x) 4.8x16 (32x) *Depending on the dimensions, there may be more / less screws 根据尺寸，螺丝的数量可能会有变化 Gispen - www.gispen.com - All rights reserved - version 07/15...
- Page 2 把框架安放于软表面上 Fasten the table legs using the socket-head Place the table legs screws 安放桌脚 用凹头螺丝固定桌脚 M8x10 (16x) Nr. 5 Adjust the height of the table 调整桌子高度 MAX. 3 X 最多3次 Gispen - www.gispen.com - All rights reserved - version 07/15...
- Page 3 用螺丝将框架固定在桌面上 M6x10 or 4.8x16 (24x) Fasten the cable tray mounting plates using the Positions of the screws screws 螺丝的位置 用螺丝固定电缆槽安装板 M6x10 or 4.8x16 (8x) Insert the cable tray connections 插入电缆槽连接件 Gispen - www.gispen.com - All rights reserved - version 07/15...
- Page 4 单独 Insert the cable tray connections 插入电缆槽连接件 Mount the cable tray onto the table 把电缆槽安装到桌子上 Turn the table 180 degrees Adjust the height of the table legs 将桌子旋转180° 调整桌脚高度 Gispen - www.gispen.com - All rights reserved - version 07/15...
- Page 5 单独 Fasten the CPU holder using the socket-head Loosen 4 socket-head screws from the frame screws 从框架上松开4个凹头螺丝 用凹头螺丝固定主机架 Nr. 5 M8x12 (4x) Nr. 5 Gispen - www.gispen.com - All rights reserved - version 07/15...
- Page 6 单独 Mount a computer onto the CPU holder 把电脑安装到主机架上 Gispen - www.gispen.com - All rights reserved - version 07/15...
