H0006358.02 www.caleffi.com Self-cleaning magnetic dirt separator strainer 579 series © Copyright 2019 Caleffi PROGRAMMING MANUAL CONTENTS Front panel Display Operating principle Menu Forcing menu Parameters menu Historic data menu Communication Information Drainage temperature limitation Faults Alarm management Actuator relay Modbus... -
Page 2: Front Panel
Front panel LED indicators: 1 Red LED: steady (alarm notification with system locked) flashing (fault, system operating) 2 Yellow LED: indication of cleaning or additives delivery in progress or resumption of operations following ✔ reset 3 Green LED: flashing (initial cleaning) steady on (normal operation) Series 579 Supply: 230V (ac) ±10%... -
Page 3: Menu
Menu To access the various menus and submenus, hold the confirm/ok button for more than 3 seconds. To navigate among the various submenus, use the “UP” or “DOWN” keys. Press the “BACK” key to return to the previous submenu and then press it again to return to the main menu, or wait 2 minutes without pressing any keys. -
Page 4: Parameters Menu
1.8 Device reset menu Use the “UP” or “DOWN” keys and select “ON” to suspend the functions in progress and reset the alarms. Restart the device and perform an internal pressure check and water filling cycle, if necessary. 2. Parameters Menu 2.1 Date/time Press “OK”... -
Page 5: Historic Data Menu
2.3.8 minute hour menu Use the “UP” or “DOWN” keys and select by means of the “ON” key. The value is the minutes of the programmed strainer cleaning start time. Set the value with the “UP” or “DOWN” and “back” keys. Confirm with “OK”. 2.3.9 Sleep weeks menu Use the “UP”... -
Page 6: Drainage Temperature Limitation
(red LED flashing on the front panel). Faults are also recorded in a specific memory zone accessible via Modbus. The fault signal persists until the user performs an alarms/faults reset, operating on the user interface or via Modbus, or when the fault in question is resolved. Contact Caleffi technical service if you are unable to solve the problem unassisted. Problem... - Page 7 Perform an alarm reset to clear the alarm. device maintenance can be carried out only by expert person- cleaning nozzles clogged nel: contact Caleffi for instructions. air vent cap tightened in closing unscrew and open the air vent cap. E 14...
- Page 8 sensor 2 erroneously removed during refit the sensor correctly and check correct sealing of the sys- operation of the device tem. Restart the system by means of an alarm reset. sensor 2 clip break inspect the plant and check that there are no faults or E 16 alarm sudden drop of plant pressure due to...
-
Page 9: Actuator Relay
Actuation relays The board features the auxiliary replay contacts used to control auxiliary equipment and alarms. input relay for voltage free contact. When the contact is closed, strainer cleaning is inhibited OUT1 relay output N.A. The contact closes when the strainer is in the cleaning phase (max 48V,1A) ALARM relay output N.A. - Page 10 MODBUS functions: Function 0x03 - Read Holding Registers Used to read one or more parameters (the size of every parameter is 16 bit) The frame has the following structure: dev. Addr. func start addr H start addr L N.regs H N.regs L CRC16H CRC16L...
- Page 11 Register Address Data Description DEFAULT Description of BIT name (DEC) type Device model, represented with MON0000 a 16-bit integer. Device communication address MON0001 or IDB, represented with an 8-bit number. Temperature measurement 1 in MON0002 tenths of a degree, represented with a 16-bit integer.
-
Page 12: Modbus
Bit 0: motor command Bit: 1 drain valve command Bit: 2 domestic water valve command status of command outputs, Bit: 3 inlet valve command MON0025 represented with an 8-bit Bit: 4 cooling output command integer. Bit: 5 inhibition output command Bit: 6 alarm output command Bit: 7 voltage free output command status of inputs, represented... - Page 13 Depending on the cleaning period setting, the register may have different definitions and contents. Daily period: register is not used be- cause cleaning is enabled every day. Weekly period: register assumes meaning of mask of days enabled for cleaning. Meaning of the configuration register bits (1=enabled,0=disabled): bit 0: Monday Enabling of disinfection bit 1: Tuesday Enabling of disinfection...
