Four BL2100 models are available. Their standard features are summarized in Table 1.
Feature
Microprocessor
Static RAM
Flash Memory
RJ-45 Ethernet Connector,
Filter Capacitors, and LEDs
A/D Converter Inputs
(-10 V to + 10 V)
D/A Converter Outputs
(0 V to +10 V)
RabbitCore Module Used
Additional 512K flash/512K SRAM memory options are available for custom orders
involving nominal lead times. Contact your Rabbit sales representative or authorized
distributor for more information.
Appendix A provides detailed specifications.

1.2.1 Connector Options

In addition to the standard screw-terminal connectors supplied on BL2100 boards, IDC
headers, bottom-mount sockets, and polarized friction-lock terminals may be factory-
installed instead. Visit our Web site at
representative or authorized distributor for further information.
Standard screw terminals, accept
up to 14 AWG (1.5 mm
IDC headers, 0.1" pitch
2
Table 1. BL2100 Models
BL2100
Yes
Yes
Yes
RCM2200
www.rabbit.com
2
) wire
BL2110 BL2120
Rabbit 2000 running at 22.1 MHz
128K
256K
No Yes
No Yes
or contact your Rabbit sales
Bottom-mount socket, 0.1" pitch
Polarized friction-lock terminals,
0.1" pitch
BL2130
No
No
No
RCM2300
