Hook Wizard Preliminary Manual page 6

Don't place anything on top off the amplifier , otherwise the cooling vent is obstructed.
Midi in
Connect a standard 5 pin din plug, other side to Midi foot controller or other midi device capable
of sending midi program changes.
Presence
Dial in your favorite setting to match your cab.
Power and Standby
Switch the Wizard "on" and wait 45 seconds to heat up the tubes, then swtich the standy to "on"
Fuses
!!ALWAYS REPLACE THE FUSE BY VALUE THAT IS WRITEN BELOW THE
COMPARTMENT!
230V countries
•
Main fuse 2A slowblow (5x20mm)
•
HT fuse 500mA fast blow (6.3x32mm)
115V countries
•
Main fuse 5A slowblow (5x20mm)
•
HT fuse 500mA fast blow (6.3x32mm)
Effectloop
Send and return to between preamp and power amp.
The Master knob is post effect loop.
Insert here your delays, reverbs and other time based effects you don't want in front of your
distortion.
Send level is 1.2V max
Tube Layout
Counted from input side.
•
V1 12ax7
•
V2 12ax7
•
V3 12ax7
•
V4 12ax7
•
V5 EL34
•
V6 EL34
preamp (channel1/2)
preamp (channel 1/2)
effectloop send and return
Phase inverter
Power amp
Power amp
