Tecson e-litro Series Start-Up & Operation

Electronic pneumatic tank measurement system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Electronic pneumatic tank measurement system
V6.x // 06-2016
Start-up + Operation
e-litro
of the
e-litro
e-litro secu4
e-litro net
e-litro gsm
for tank sizes up to max. 10,000 liters
CONTENT:
Regualtions and maintenance
Setup and Operation
®
series
SW-Version V6.0x
SW-Version V6.0x
SW-Version V6.0x
SW-Version V6.0x
4
4
6
7
10
11
12
14
15
17
18
20
P. 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the e-litro Series and is the answer not in the manual?

Questions and answers

Related Manuals for Tecson e-litro Series

Summary of Contents for Tecson e-litro Series

  • Page 1: Table Of Contents

    Start-up + Operation Electronic pneumatic tank measurement system e-litro ® of the series e-litro SW-Version V6.0x e-litro secu4 SW-Version V6.0x e-litro net SW-Version V6.0x e-litro gsm SW-Version V6.0x for tank sizes up to max. 10,000 liters CONTENT: Installation and mounting Control elements and display ALARM and QUIT-button for secu4 Device setup and programming...

  • Page 2: Installation And Mounting

    (data transfer via RDT). The devices of the e-litro series are equipped with a power plug for 230V sockets. The transducer (sensor) is connected to the measuring input of the e-litro displaying device.
  • Page 3 e-litro secu4: secu4 device is an oil tank measuring system for battery tank systems. The complete set consists of the displaying device and the sensorbox which has to be mounted close to the tank. The sensorbox of the secu4 has 4 measuring hose inputs to measure and observe 4 single tanks of one tank-battery at the same time.

  • Page 4: Control Elements And Display

    Control elements and display First determine the container data and then enter the data into the device menu. The programming is described in the following pages. To setup the displaying device the lid has to be twisted off. Perform the device setup once at the initial startup.
  • Page 5 Under menu item 5b the filling limit is to be adjusted to the limit indicator height as accurate as possible. Password: The device settings can be protected by activating a password under menu item 8. A forgotten password can be requested by contacting TECSON. Resetting the secu4 will cause the device to demote in a non programmed state...

  • Page 6: Alarm And Quit-Button For Secu4

    secu4 display with 3 or 4 tanks: Regular display: In case of a battery tank system with 3 or 4 tanks the display will switch over. Thereby the single tank display and the inventory and clearance display are shown alternately. Switch-over =>...

  • Page 7: Device Setup And Programming

    Device setup and programming Press [Enter] to open the menu. The menu offers the menu steps 1 … 7. Menu steps 9 … 24 offer special advanced options. Only one level sensor can be connected to the instruments e-litro net / e-litro gsm. Using the e-litro displaying device either one or two LITRO-Sensors can be connected.
  • Page 8 3. Tank shape Selection of tank shape: Alternatively just 1 special tank geometry can be setup by a ‘Bearing chart’ for liter conversion. Linear Default: Linear tank. Rectangular tank/ vertical cylinder/ steel cellar tank. Cylindric horiz Cylindric tank. Horizontal cylinder/ tubular container. Typical tank shape for outdoor tanks and buried steel tanks.
  • Page 9 Description Input function: Device type Menu functions 4. Tank volume Enter the tank’s volume by [+] [-]. ( 100% value) Default is 0 L. This value must be entered. maximum volume: Attention, in case of an existing bearing chart: 10,000 L Please use the pair of values for 100% for tank volume and tank height from the table.

  • Page 10: Programming Examples

    The qualified technician should note down the password and store it appropriately. loss of If the password is lost please contact TECSON. password Therefore please have the serial number of the device ready! Menu item 9 – 24 Steps 9 –...

  • Page 11: Tank With Interior Mantle

    Example 2 Buried tank, cylindric horizontal, for 10,000 liters diesel, Inner height 1.59 m, (filling level 54 cm), LITRO-level probe 0 - 250 mbar e-litro gsm Device with SIM card: Menu item Setting / Selection 1. Measuring probe 250 mbar 2.

  • Page 12: Special Settings

    Special settings Description Input function: Device type Additional functions Menu items 1 to 7 The menu items 1 to 7 are the basic setup of the devices. see pages 7-9 Some special settings, e.g. language, network parameters or others, have to be set up via menu items 9 to 24. Sub-menu a.
  • Page 13 15. Network e-litro net DHCP . . . only for Sub-menu for network parameter e-litro net setup like IP address, message destination and communication test. Please coordinate these settings with your network admin. See additional documentation ’network device connection’. e-litro gsm only for - Send SMS .

  • Page 14: Error Messages / Error Indication

    Description Input function: Device Additional functions type 20. LCD Display By factory the contrast of the LCD display is preset as: Contrast: xx (xx is a hexadecimal value) 21. Device-info Shows: Software version : V6.01 ( e.g. ) Serial no. : Tank i: SN=1234 ( i = Tank-no.) Offset + Gain...

  • Page 15: For Device Type E-Litro Net

    Error code Meaning Error Invalid input value. Error Signal value of the LITRO-sensor is too small (signal current less than 3.7 mA). In case of the secu4 the sensorbox transmits invalid data (probe error). Disconnect the current supply and turn the device back on. If the error lasts for at least 5 min.
  • Page 16 Info/Error-Messages at Network Communication Error No network communication. Problem with the internal network module. The device automatically executes a ’reset’ for the internal network module and retries communicating. Try disconnecting the power supply, wait… and reconnect. Error Error in the network communication. Signal destination cannot be reached / data sending impossible.

  • Page 17: For Device Type E-Litro Gsm

    e-litro gsm For device type Error messages GSM module / SIM card / Mobile network Error GSM modem is inactive. Entering PIN => 0000 completely deactivates the modem. Error Internal communication error. The device automatically executes an internal RESET and retries communicating with the internal modem. Error SIM card is not inserted, is not readable or is defective.

  • Page 18: Electrical Connections

    Electrical connections for e-litro = slot for adaptors: M-BUS ; 0-5 V outlet ; 4-20 mA outlet ; link adaptor Clamp contact number: 1: LITRO-sensor input (+) (red or white or blue) 2: LITRO-sensor input (‒) (brown or black) 3 + 4: Input for a second LITRO-sensor (this option is not equipped) Rightmost clamping block: AC 230V N/L supply Electrical connections for...
  • Page 19 Electrical connections for e-litro net / e-litro gsm Clamp contact number: 1: LITRO-Sensor input (+) (red, white, blue) 2: ditto (‒) (black, brown) 3: data input for additional e-litro device ( + ) 4: ditto (‒) 5: alarming contact input ( + ) 6: ditto (‒) 7 + 8: relay output: opening contact (normal status is closed)
  • Page 20 Then the display has to show Error E008, by means the test was successful (OK). Otherwise the check was not successful! In that case please send in the sensorbox to TECSON to be repaired. TECSON GmbH & Co. KG Producer: Tel.
