Operation
Some colors or
the strobe effect
on this list may
not apply to your
ILUMINARC® product.
Consult the product's
manual for more
information.
DIM1 is the
fastest dimming
curve and DIM4
is the slowest.
8

Static Colors

1. Go to STATIC.
2. Select a color or effect (RED, GREN, BLUE, COOL, WARM, AMBE, SOLD, or
STRB).
3. Select a color value (000~255) or a strobe frequency (00~20).

Dimmer

This setting gives the user four different options to simulate the dimming curve of an
incandescent lighting product.
1. Go to DIMMER.
2. Select a dimming curve (OFF or DIM1~4).
Procedure:
DIMMER
OFF
DIM1
DIM2
DIM3
DIM4
Color (
Full Color Products
1. Go to SETTINGS > COLOR.
2. Select the color method (OFF, RGB TO W, UC).
Details:
OFF
When the RGB faders are all set to "255," the output is maximum.
RGB TO W
When the RGB faders are all set to "255," the output is the selected White color
(see Whites Setting).
UC
When the RGB faders are all set to "255," the output matches the same color output of
previous versions of this product.
Whites Setting (
Full Color Products
1. Go to CALIB.
2. Select a white color (WHITE 1~11) or RGB TO W.
3. Select an RGB color (RED, GREN, BLUE, COOL, WARM, or AMBE).
4. Configure the color value (000~255).
5. Repeat steps 3 and 4 for the other RGB colors to obtain a white color.
6. Repeat steps 2 through 5 for the other white colors.

Reset to Factory Settings

1. Go to SETTINGS > RESET.
2. Select an option (YES/NO).
Details:
The product will assume its default values as per the corresponding manual.
Description
Dimmer curve is linear with fader
Non-linear (fastest)
Non-linear (fast)
Non-linear (slow)
Non-linear (slowest)
)
)
